Low Noise High Speed Long Life BLDC 3525 12V 24V

US$1.00 1 Piece (MOQ)

Basic Info.

Model NO.
ZC-B004
Number of Stator
Two-Phase
Excitation Mode
VR-Variable Reluctance
Function
Control, Driving
Number of Poles
12
Operate Mode
Three-Phase Six-Step
Type
Magnetic-Electric
Certification
ISO9001
Brand
Zucoo
Colour
Customized
Size
Customized
Thickness
Customized
Transport Package
Carton
Specification
As according to customers′ request.
Trademark
ZUCOO
Origin
China

Product Description

Product model zcBLDC3525 Shaft length 9mm (plane of motor case to shaft head)
Operating Voltage 12-24V Shaft diameter 3mm
power 2.5W Drive mode Built-in sensed Hall drive
Product Size 35*25*9mm Firmware performance 4-pole magnetic brushless stator, 6-slot structure of brushless rotor
weight 66g Outside diameter size 36mm length size varies according to different parameters
General parameters: 12V,3000rpm,6000rpm. 24V,5000rpm, 6000rpm.Other parameters need to be customized

BringSmart Customized manufacturersbl dc Planetary dc motor gearbox 12v 24v DC Worm Gear Motor 110V 220V AC Asynchronous Motor Warranty: 3months-1year
Place of Origin: Fujian, China
Brand Name: BringSmart
Model Number: Hot Sale Models
Usage: BOAT, Car, Electric Bicycle, FAN, Home Appliance, Cosmetic instrument, SMART HOME, Vending Machine,DIY BBQ,Electric Curtain
Type: GEAR MOTOR
Torque: 0.014-435KG.CM
Construction: Permanent Magnet
Commutation: Brush
Protect Feature: Totally Enclosed
Speed(RPM): 0.9-8000RPM
Continuous Current(A): /
Efficiency: IE 2
Product Name: BringSmart Hot Sale Motors
Certification: CCC, CE, RoHS
Product name 1: electric motor
Product name 2: Low RPM motor
Product name 3: Small electric motor
Product name 4: Asynchronous Motor
Product name 5: BLDC Brushless Motor
Product name 6: small gear motor COAXIAL CABLE STRIPPER/NETWORK TOOL

The length of shaft can be customized, Please contact me.

Reference Datasheet

PMDC MOTOR Technical Date
Model
Rated Voltage(V)
No-Load
Rated
Stall
Operating Range
Nominal
Speed
Current
Speed
Current
Torque
Power
Current
Torque
RPM
A
RPM
A
mN.m / gf.cm
W
A
mN.m / gf.cm
RS-550H
23128R
6.0~24.0
24VDC
4500
0.1
3932
0.39
25.7/262
10.6
4.8
204/2080
6034
6.0~12.0
12VDC
16000
1.12
13613
4.96
25.6/261.3
40.36
48.89
281.4/2870
Product name 7: dc gear motor 3v The motor types are various, send us your technical requirement, We will recommend suitable model according your request, any question, Please click on this link to contact us. DC High Speed Motor Series Customized Service We can customize various shafts, terminal , gearboxes, code discs, etc. according to your requirements. Please send an inquiry or TM to tell us.
