US$1.00
|
1,000 Meters
(MOQ)
|
Basic Info.
Safety Design
Environmental Design
Wear Resistant
Highly-Elastic
Stiffness & Flexibility
Flexible Shaft
Axis Shape
Straight Shaft
Transport Package
Carton, Pallet, Woven Bags, or as Your Request
Specification
ISO9001: 2008; SGS
Production Capacity
200000 Meters Per Month
Product Description
Structure: 70#~75# high-carbon steel wire
Direction of Twist: Levorotation and dextrorotation
Applicable Scope: Vibrating machine, automobile, motorbike, counter, revolution counter, electric tools, gardening machinery mower, and various mechanical flexible rotations.
Function: Smooth, flexible, highly-elastic, and wear resistant
Diameter (mm)
| Tolerance (mm)
| Number of Layers
| Loading Moment
(N @ m)
(Sample 500mm Long)
| Weight
(kg/ 100m)
|
2.0
| +0.02
-0.02
| 3/5
| 0.8
| 1.8
|
2.5
| 3/5
| 1.0
| 2.8
|
3.2
| 3/5
| 1.3
| 4.6
|
3.8
| 3/5
| 1.5
| 6.5
|
5.0
| +0.00
-0.05
| 3/4/5
| 1.8
| 11.3
|
6.0
| 3/4/5
| 2.4
| 16.2
|
6.5
| 4/5/7
| 2.9
| 18.7
|
8.0
|
| 4/5/6/7
| 7.5
| 28.8
|
10
| 4/5/6/7
| 22.5
| 45.5
|
12
| 4/5/6/7
| 39.0
| 66.5
|
13
| 4/5/6/7
| 50.5
| 77.5
|
16
| 4/5/6/7
| 115.0
| 114
|
18
| 4/5/6/7
| 160
| 145
|
| The flexible shafts not listed in the chart can be customized |
>>
