Mono Block Structure Bridge Cutting Machine

Product Description

Mono-block Bridge Cutting Machine
Model YTQQ-500
YTQQ-500 Mono-block Bridge Cutting Machine High efficiency for cutting slab & tile, flexible, accurate and reliable. With the mono-block structure, installation is not necessary for this machine, and it brings much convenience to users.
Technical Parameter

	YTQQ-500
Max. dia. of blade/mm	500
Worktable tilting degree	0-85
Cutting head rotary degree	90
Max. cutting dimension(LxWxH)/mm	3000X1800X130
Main motor power/kw	15
Power requirement	3 Phs 380V 50Hz(other is available)
Water consumption/ cbm/h	4
Overall dimension(LxWxH)/mm	5800X2700X2500
Total Weight/kg	6,000

Feature
l Mono-block structure, side beams are fixed on the steel, solid and stable.
l Equipped with infrared device for precise cutting location
l Wide crossbeam of bridge structure for large size of slab cutting and it is made of strong cast iron to avoid distortion after long-term use.
l Guide rail on the crossbeam is in oil bath and it is protected from water and dust
l Dustproof design of the slide track ensures the precise guide movement & long lifespan
l Vertical movement of machine head is driven by accurate hydraulic system, and the stroke is adjustable
l Cross movement of the machine head on the crossbeam is driven by motor equipped with OMRON rotary encoder by which the precision is guaranteed
l The crossbeam is installed on the side beams by lineal guide track that results in less friction force and provides better flexibility and reliability
l Worktable can tilt 0-85°
l The blade head can rotate 90° by hydraulic system to cut the other side of slab without turning its direction
l Equipped with PANASONIC frequency transducer and PLC, programmable and fully automatic
l Touch-sensitive operating system, friendly human-machine interface design

Our Services - Fast Response
- OEM Available
- Technology Support
Company Information 23 years of experience in diamond tools industry;
900 experienced employees;
2100 clients from 108 countries and regions;
200,000 pieces segments of daily production output.
Found in 1993, Fujian Wanlong Diamond Tool Co.,Ltd is a professional producer of diamond tools,located in Quanzhou City of Fujian Province,one of the biggest stone processing centers in the world.
The factory covers an area of modern standard factory workshops,office buildings and dormitories. It is equipped with the most advanced production and testing equipments for diamond tools manufacturing sectors. The experienced and devoted employees working in a friendly family atmosphere in our research,development,production,sales and customer service sections,Wanlong is now one of the biggest manufacturers of diamond tools for stone processing.
What makes us outshine from other diamond tools suppliers is that,wanlong owns a stone machinery factory and a stone processing factory,which offers Wanlong diamond tools innovation team good testing opportunities each and every new formula is test ed in our new factory before sending to the market,to ensure the fastest and precise feedback.
FAQ 1. We are considering to buy Chinese products, how can I know the quality whether it is suitable for our factory or market?

Now more and more people in the world like to use Chinese products though the quality is not the best while the price is very cheap. We are most professional in stone cutting this field for many years. If not available we think a small amount trial order for testing is necessary, otherwise you will never know the performance of Chinese products.

2. What is the minimum quantity we should buy?

For sample purpose we don't mind how much you buy, we will send the samples by courier(DHL, TNT, UPS, EMS, etc).

3.As I know many companies supply free samples, do you offer free samples?

We don't offer free samples, according to our years' experience we think when people get the samples by paying they will cherish what they get. Although the quantity of sample is small however its cost is higher than normal production.

4. What is your mode of payment?

For Air Cargo the payment should be T/T of total amount before shipment, for Sea Cargo other terms to be negotiated.

5. If we make the payment, how long you will make the shipment?

It depends on the quantity of order, as usual we make the shipment within 7-10 days on receipt of payment. For special order(Such as big order or not standard specification order) it may cost more days. We always let our customers know how many days he should wait before or after he place an order.

---
