Goman Spider Lift 18m X18 with CE and EPA

Product Description

Standard FeaturesStandard Features Goman spider lift 18m X18 with CE and EPA Trailer Fold Arm Lift Platform is suitable for indoor and outdoor work, the platform height ranges from 8-22 meters, load capacity can reach 200 kg, the size can be customized, and the user-friendly design.
Multiple power sources: AC, DC, diesel engine and gasoline engine power all are available, suitable for a variety of working conditions.
1.Two sources of power: Storage battery and Diesel engine. And the storage battery works without noise. 2.Four full-automatic hydraulic legs,provide great stability for the equipment.
3.Boom rotation 360°,so it can work across the barriers .
Features: Wireless remote control for all movement
Cable control integrated radio control
Automatic outrigger self-leveling
Self-leveling & rotatable basket,AC 16A outlet in the basket
Extendable crawlers
Black rubber crawlers
Foot switch
Hydraulically arms and outrigger interlock
Made of high tensile steel
Reach standard of ISO, CE and ANSI
Parameters:
Application: Trailer boom lifts are widely used in highways, boat yards shopping walls, stadiums, dock, station, marketplaces, gymnasiums and residential property, workshop,residential property, mining workshops and any other isometric maintenance operation of complex high-altitude construction and other large range homework place. Attention about trailer boom lift: 1. When the platform works, the work bench should be horizontal 2. When work outdoors, workers should wear safety rope when the platform is higher than six meters. 3. In the process of lifting platform, anyone is prohibited from climbing. 4. Forbid working until support legs are right. After littered, platform should not be moved.

Applicable Industries Advertising Company, Building Material Shops, Construction works , Energy & Mining, Farms, Food & Beverage Factory, Food & Beverage Shops, Food Shop, Garment Shops, Home Use, Hotels, Machinery Repair Shops, Manufacturing Plant, Printing Shops, Restaurant, Retail, Other Showroom Location Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Chile, Sri Lanka Place of Origin China Table Size 1.4*0.7*1.25m Weight 4650 kg Machinery Test Report Provided Video outgoing-inspection Provided Marketing Type Ordinary Product Warranty of core components 2 years Core Components Pressure vessel, Motor, Bearing, Gear, Pump, Engine Condition New Lift Mechanism Scissor Lift Lift Drive / Actuation Electric Motor Power 48V/60A Min. Lifting Height 0.26m Overall Dimensions 4.95*2.9*1.71m Product name Spider lift Model x18 Work Height 18m Platform Height 16m Platform Capacity 230kg(restricted)/120kg(unrestricted) Hydraulic Tank Capacity 50L Ground Pressure When Driving 33.68kN/m² Ground Pressure When Working (Standard) 2.05kN/m² Ground Pressure When Working (Narrow) 2.45kN/m²

---
