IP 65 VSD Factory Supplier with Waterproof High Quality

Product Description

1. Specification

Model			S2100S
Input	Rated voltage,Frequency		3 AC 380V / 220V; 50-60 Hz
	Voltage Range		380V: 330V~440V;220V: 170-240V
Output	Voltage Range		380 V: 0~380 V; 220V: 0-220V
	Frequency Range		0.10~400.0 Hz
Control method			V/F control,Space verctor control
Indication			Operating status/Alarm definition /interactive guidance;eg,frequency setting,the output frequency/current,DC bus voltage,the temperature and so on.
Control Specification		Output Frequency Range	0.10~400.00 Hz.
		Frequency Setting Resolution	Digital input: 0.01 Hz. Analog input:0,1% of maximum output frequency
		Output Frequency Accuracy	0.01 Hz.
		V/F Control	Setting V/F curve to satisfy various load requirements
		Torque Control	Auto increase:auto raise torque by loading condition;Manual increase:enable to set 0.0~20% of raising torque
		Multifuncional Input Terminal	8 multi-function input terminals,realizing function including fifteen section speed control,program running, four-section acceleration/deceleration speed switch,UP/DOWN function and emergency stop and other functions
		Multifuntional Output Terminal	3 multi-function output terminals for displaying of running,zero speed,counter,external abnormality,program operation and other information and warnings

2. Advantage :

Big savings on installation:
With a built in RFI filter, the S2100S IP65 inverter can be positioned close to the motor which cuts thecost of shielded motor cables. Choose the version with integrated insulator to simplify your external connections.
Big performance:
The S2100S IP65 is a modern sensorless vector inverter with 200% overload capacity, a wide range of supply and fieldbus options, and excellent I/O.

Big advantages of easy handling:
The S2100S IP65 inverters integrate the EPM memory module - a simple plug in chip that stores all the drive settings. The EPM module can be programmed off-line and the settings transferred from drive to drive in seconds. In the unlikely event that a drive fails, the EPM guarantees you minimum downtime.
3. FAQ

Q: What is your payment ?
A: Our payment is by T/T. Western Union. and Money.

Q: Is there a discount on the price of your product?
A: It depends the quantity of order.

Q:Is same quality between the sample and big order?
A:Our products are always as good as the samples we send, I can promise there will be no debasement of quality.

Q:Is the price for FOB?
A:Yes.

Q: How much is your minimum order quantity?
A: one pcs or unit.
4. Keywords:
AC frequency inverter, Variable frequency drive, AC drives
Variable Frequency Drive / Variable Speed Drive / frequency converter / AC converter
Frequency Inverter / AC Driver / AC Drives / AC Motor Drives / VFD, VSD / transistorized drives

5. Additional info.
(1). More than 20 years-- manufacture of frequency inverter.
(2). More than 10 years-- experience in OEM items
(3). More than 60 countries-- exported
(4). More than 70 R&D team-- OEM, ODM accepted
(5). More than 10,000 pcs production capacity per month
(6). Certification-- CE, ISO9000, ISO14001, OHSAS18000
(7). Service-- Stand on customer's position to solve problem, reply within 24 hours

---
