| US$5,000.00 | 1 Piece (MOQ) |
| PRODUCT FEATURES | |||
| *THE SURFACE OF THE BEDWAYS IS SUPERSONIC FREQUENCY HARDENED. *GEARS PRECISELY GROUND TO REDUCE NOISE. *SPINDLE SYSTEM IS OF HIGH RIGIDITY AND PRECISION. *RAPID FEED STRUCTRUE IS AVAILABLE ON APRON. *INTEGRAL CASTING BASE CAN BE OPTIONAL. | |||
| TECHNICAL PARAMETERS | |||
| SPECIFICATION | LC320/1000MM | LC360/1000MM | |
| CAPACITY | Max.swing over bed | 330mm | 360mm |
| Max.swing over cross slide | 198mm | 212mm | |
| Max.swing over gap | 476mm | 491mm | |
| Center Distance | 1000mm | ||
| Bed Width | 187mm | ||
| HEADSTOCK | Spindle hole | 38mm(51mm for optional) | |
| Spindle nose | ISO-D4 | ||
| Spindle taper | MT5 | ||
| Spindle speed(Number) | (8steps)70-2000rpm | ||
| FEEDS AND THREADS | Max.travel of top slide | 95mm | |
| Max.travel of cross slide | 180mm | ||
| Max.size of toolshank | 16*16mm2 | ||
| Metric threads range | 0.25-11mm | ||
| Inch threads range | 4-112 T.P.I | ||
| TAILSTOCK | Dia.of tailstock sleeve | 32mm | |
| Taper of tailstock sleeve | MT3 | ||
| Max.travel of tailstock | 100mm | ||
| MOTOR | Main drive motor | 1.5KW | |
| Coolant pump motor | 40W | ||
| PACKING | L*W*H | 195*76*155cm | 195*76*155cm |
| WEIGHT | N.W/G.W | 520/640kgs | 570/690kgs |
| ACCESSORIES | |||
| STANDARD ACCESSORIES | |||
| PART:INSTALL ON THE LATHE | |||
| 3-jaw chuck(Φ160mm) | |||
| Steady rest & follow rest | |||
| Thread-cutting dial | |||
| Longitudinal touch stop | |||
| Work lamp | |||
| Coolant system | |||
| Full-length splash guard | |||
| Foot brake and brake ribbon | |||
| PART:INSIDE THE PACKAGE WITH THE LATHE | |||
| 4-jaw chuck(Φ200mm) | |||
| Face plate | |||
| Dead centre and centre sleeve | |||
| Oil gun | |||
| Paddings | |||
| One whole set spanner and tool box | |||
| Operation manual | |||
| SPECIAL USE ACCESSORIES(OPTIONAL PIRCE) | |||
| Live centre(MT3) | |||
| 2axis Digital readouts(SINO) | |||
| 3axis Digital readouts(SINO) | |||
| Chuck guard,Toolpost guard and leadscrew guard | |||
| USA type Quick change tool post | |||
| Europe or Italy type Quick change tool post | |||
| Drill chuck set | |||
| Cutting tool holders set(7pcs or 9pcs) | |||
