Product Description
Product Description
Product Description
Pad Printing Machines Sealed Ink Cup Ceramic Doctor Ring, it is suitable for Kent, Winnon, Chougfou, Everbright Machines.
Item
| Unit
| Zirconia
|
Composition
| wt%
| 94.6%ZrO2,5.4%Y2O3
|
Density
| g/cm3
| 6
|
Hardness
| HV(HRC)
| 1200(70)
|
Bending Strength
| MPa
| 1150
|
Fracture Toughness
| MPa.m1/2
| 9
|
Modulus of Elasticity
| GPa
| 205
|
Thermal Conductivity
| W/mk
| 3
|
Thermal Expansion Coefficient
| 10-6/k
| 10.5
|
Packaging & Shipping
Package: plastic ring and paper box,1 pc/box
Shipping: by express
Our Services
16 hours online service
Company Information
We supply you printing machines of pad printing, screen printing and hot stamping and all kinds of printing accessories.
FAQ
Can I order 1 pc of doctor ring each time?
Yes, you can.
>>
