Max Resolution: 2MP (1920×1080), Max Output: Full HD 1920×1080@30fps Live Image Support H.265/H.264/MJPEG Video Compression Algorithm, Multi-level Video Quality Configuration and Encoding Complexity Settings Starlight Low Illumination, 0.0005Lux/F1.4(Color),0.0001Lux/F1.4(B/W) ,0 Lux with IR 92x Optical Zoom, 16x Digital Zoom Support Motion Detection Support 3-stream Technology, Each Stream Can Be Independently Configured With Resolution And Frame Rate ICR Automatic Switching, 24 Hours Day and Night Monitor Support Backlight Compensation, Automatic Electronic Shutter, Adapt to Different Monitoring Environment Support 3D Digital Noise Reduction, High light Suppression, Electronic Image Stabilization, 120dB Optical Width Dynamics Supports Optical Defog, Maximum Improves The Foggy Image Support 255 Presets, 8 Patrols Support Timed Capture and Event Capture Support One-click Watch and One-click Cruise Functions Support One Channel Audio Input and Output Support Alarm Linkage Function with Built-in One Channel Alarm Input and Output Support 256G Micro SD / SDHC / SDXC Support ONVIF Optional Interfaces for Convenient Function Expansion Small Size and Low Power, Easy to Inset PT Unit, PTZ
| Specifications |
| Camera | Image Sensor | 1/1.8" Progressive Scan CMOS |
| Minimum Illumination | Color:0.0005 Lux @ (F1.4, AGC ON); B/W:0.0001Lux @ (F1.4, AGC ON) |
| Shutter | 1/25s to 1/100,000s; Support delayed shutter |
| Aperture | PIRIS |
| Day/Night Switch | ICR cut filter |
| Digital zoom | 16x |
| Lens | Focal Length | 6.1-561mm, 92x Optical Zoom |
| Aperture Range | F1.4-F4.7 |
| Horizontal Field of View | 65.5-1.1° (wide-tele) |
| Minimum Working Distance | 100mm-3000mm (wide-tele) |
| Zoom Speed | Approximately 7s (optical, wide-tele) |
| Compression Standard | Video Compression | H.265 / H.264 / MJPEG |
| H.265 Type | Main Profile |
| H.264 Type | BaseLine Profile / Main Profile / High Profile |
| Video Bitrate | 32 Kbps~16Mbps |
| Audio Compression | G.711a/G.711u/G.722.1/G.726/MP2L2/AAC/PCM |
| Audio Bitrate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) |
| Image(Maximum Resolution:1920*1080) | Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps(1920 × 1080, 1280 × 960, 1280 × 720) |
| Third Stream | 50Hz: 25fps (704×576); 60Hz: 30fps (704×576) |
| Image Settings | Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browser |
| BLC | Support |
| Exposure Mode | AE / Aperture Priority / Shutter Priority / Manual Exposure |
| Focus Mode | Auto Focus / One Focus / Manual Focus / Semi-Auto Focus |
| Area Exposure / Focus | Support |
| Optical Defog | Support |
| Image Stabilization | Support |
| Day/Night Switch | Automatic, manual, timing, alarm trigger |
| 3D Noise Reduction | Support |
| Picture Overlay Switch | Support BMP 24-bit image overlay, customizable area |
| Region of Interest | Support three streams and four fixed areas |
| Network | Storage Function | Support Micro SD / SDHC / SDXC card (256g) offline local storage, NAS (NFS, SMB / CIFS support) |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G) |
| Interface | External Interface | 36pin FFC (Network port, RS485, RS232, SDHC, Alarm In/Out
Line In/Out, power) |
| General | Working Temperature | -30ºC~60ºC, humidity≤95%(non-condensing) |
| Power supply | DC12V±25% |
| Power consumption | 2.5W MAX (ICR, 4.5W MAX) |
| Dimensions | 175.5x75x78mm |
| Weight | 950g |
