Xe150d 15ton Crawler Excavator with Cummins Engine on Sale

US$40,000.00-150,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
XE150D
Bucket
Grab Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
1.0~1.5m³
Size
Medium-Sized
Certification
CE, ISO9001: 2000
Condition
New
Operating Weight
14400kg
Standard Bucket Capacity
0.52-0.61m3
Engine Model
Cummins 4btaa3.9
Rated Power/Speed
85.4/2200 Kw/Rpm
Max. Torque/Speed
447/1500 N.M
Travel Speed
5.2/3.4 Km/H
Max. Gradeability
>35
Ground Pressure
38kpa
Dimension
7801*2590*2880mm
Transport Package
Nude Package
Specification
ISO9001
Origin
Jiangsu Province
HS Code
84295212
Production Capacity
100/Month

Product Description

Features of XE150d 15ton Crawler excavator with Cummins Engine on Sale
1.Maximum Digging Height: 8641 MM
2.Maximum Digging Depth: 5538 MM
3.Travel Speed: 5.2/3.4 KM
4.Max. dumping height: 6181 MM
5.Machine Weight: 14400KG
6.Bucket capacity: 0.52-0.61 M3
Paraments of XE150d 15ton Crawler excavator with Cummins Engine on Sale Model Unit XE150D

Operating weight
kg 14400
Standard bucket capacity m³ 0.52-0.61
Engine Engine Model / CUMMINS 4BTAA3.9
Direct injection / √
Four strokes / √
Water cooling / √
Turbo charged / √
Air to air intercooler / √
No. of cylinders / 4
Rated power/speed kw/rpm 85.4/2200
Max. torque/speed N.m 447/1500
Displacement L 3.927
The main performance Travel speed km/h 5.2/3.4
Swing speed r/min 12.3
Max. gradeability / ≥35
Ground pressure kPa 38
Max.Bucket digging force kN 85
Max.arm crowd force kN 65
Max.traction force kN 135
Hydraulic system Main pump / 2
Rate flow of main pump L/min 2×120
Max pressure of prime relief valve MPa 31.4/34.3
Max pressure of travel system MPa 34.3
Max pressure of swing system MPa 25
Max pressure of pilot system MPa 3.9
Oil capacity Fuel tank capacity L 250
Hydraulic tank capacity L 130
Engine lubrication L 14
Overall dimensions A Overall length mm 7801
B Overall width mm 2590
C Overall height mm 2880
D Overall width of upperstructure mm 2512
E Track length mm 3660
F Overall width of undercarriage mm 2590
G Crawer width 600
H Track length on ground mm 2910
I Crawer gauge mm 1990
J Clearance under counter weight mm 964
K Ground clearance mm 478
L Min.tail swing radius mm 2325
Working range A Max. digging height mm 8641
B Max. dumping height mm 6181
C Max. digging depth mm 5538
D 8inch horizonal digging depth mm 5287
E Max. vertical wall digging depth mm 4727
F Max. digging reach mm 8296
G Min. swing radius mm 2335
Angle of arm deflection Degree --

Trade Terms forXCMG XE150d 15ton Crawler excavator with Cummins Engine on Sale
1.Method of shipment: container/ Roro
2.Payment term: T/T(30% pre-payment in advance, the balance payment before shipment.)
3.Delivery term: in 7-15 days after receiving the pre-payment.
4. The guarantee period: One year warranty service.
5.Spare parts can be supplied at any time.
