US$499.00-888.00
|
1 Piece
(MOQ)
|
Basic Info.
Controlling Mode
Artificial
Automatic Grade
Automatic
Cylindrical Grinder Type
End Cylindrical Grinder
Certification
GS, CE, RoHS, ISO 9001
The Maximum Grinding Length
700mm
Grinding Wheel Travel
740mm
Apply The Blade Width
0-40mm
Speed of Grinding Travel
2800r/Min
Transport Package
Fumigation-Free Wooden Case
Specification
600*1120*1330mm
Production Capacity
1000 Sets / Month
Product Description
Safe and available grinder / grinding machine / milling machine
Product Description : 1.Introduction of milling machine:
Automatic sharpener for sharpening planer and other same size straight edge of the tool, can wear a different angle of the straight blade cutter, equipped with an automatic cooling system.In terms of manufacturing, high-quality materials, sophisticated equipment, advanced processing technology made of, double steel sink rails join it greatly improves the pulley sliding precision, friction is small, lightweight slide, 90 ° rotary knife seat designed to meet different angles sharpening tool. Cooling water pump can effectively cool the parts of grinding, wood machine lubrication , therefore has a very high stiffness, wear resistance, impact resistance, smooth high-speed, low vibration, low noise, precise and reliable fine features.
Automatic Grinder main features:
1. A multi-use, fully functional.
2. At the same grinding planer multi-chip high efficiency, in particular between the sheet size to ensure consistent weight, the balance in favor.
3 high-precision linear bearings and linear rod reciprocating motion, time-saving, lower than the trough box so that both sides of the knife, grinding wheel rotation splashing water and miscellaneous grains all fall on the tank, clean, but also more secure. 2.Technical parameters of milling machine:
| Model | HT-MF256 |
| The maximum grinding length | 700mm |
| Grinding wheel travel | 740mm |
| Apply the blade width | 0-40mm |
| Speed of grinding travel | 2800r/min |
| Blade slope | 0°-90° |
| Motor power | 1.5kw |
| Voltage | 380V 50Hz( or customized) |
| Weight | 180kg |
| Grinding wheel size | 125*32*60# |
| Dimension | 600*1120*1330mm |
| Blade fixed mode | tapping holes fixed |
Product Picture :
Packaging Delievery :
Certifications :
Our Customers :
Contact Us :
>>
