DAB Combine Am FM Antenna for Car Rear Roof

US$5.50 2,000 Pieces (MOQ)

Basic Info.

Model NO.
ATC-M011
Material
Fr4/TPU/Copper/Rg174u
Sturcture Form
Mounted on Rear Car Window by 3m Glue
VSWR
1.5~2
Frequency
1575.42±1.023MHz
Mounted with Car
Sticked on Car Window by 3m Glue
Connector
F Type/SMA/Fakra or Others
Usage
TV Antenna, Car Antenna
Usage Occasion
Car Antenna
Base Antenna
High Gain Antenna
Nature of Operation
Receiving Antenna
Operating Wavelength
170-230MHz, 470-862MHz
Transport Package
Poly Bag/Color Box/Double Blister
Specification
RoHS, ISO/TS16949-2009
Trademark
ATC
Origin
China
HS Code
8529109090
Production Capacity
20, 000PCS/Month

Product Description

company information Antenna Technology is a high-teach company in Guangdong Province. It is professionally engaged in designing, manufacturing and selling Car Antenna and mobile communication products, we always keep an eye on your demands and the developing trend of this industry, and have established a complete products system of car antenna.
Our company has 10 years experience in manufacturing car antenna.The superior engineers provide precondition for product innovation, perfect production and testing equipment provide the quality guarantee for our products.
As the international enterprise, we are aiming at bringing customers the highest quality products to satisfy your expectation and needs, a large group of skilled technician work hard in order to increase the benefit for customers.
specification
Origin China
Brand ATC
Model ATC-M011
Warranty 3 years
DAB Frequency range 170-237MHz(Band Ш)
Output Gain 12dB-18dB (Band Ш)
Output impedance 75 ohms
V.S.W.R 3:1
Noise Figure less than 2dB
AM/FM Frequency range am:520-1620KHz ,fm:87-108MHz
Gain 7-12dB
Operating Voltage DC10.5V-16V
Operating Current 30mA-50mA
Work Temp -30ºC--+80ºC
Storage Temp -30ºC--+85ºC
Cable spec 1.5DSQEHV ,for DAB ,1.5C2V for radio
Connector SMA/SMB/FAKRA or Others for DAB , Motorola din plug for radio
packing
pratical application
