SGA40100AH/AHR/AHD horizontal surface grinding machines for metalwork

Product Description

Product Description
Fearures:
AH means: Auto intermittent feed on transverse, hydraulic transmission on longitudinal, manual on vertical.
AHR means: Auto intermittent feed on transverse, hydraulic transmission on longitudinal, rapid movement on vertical.
AHD means: Auto intermittent feed on transverse, hydraulic transmission on longitudinal, PLC auto grinding controller and servo motor is equipped and with wheel head auto down feed.

Model		Unit	SGA40100AH/AHR/AHD
Table size(WxL)		mm	406x1005
Max.longitudinal travel		mm	1130
Cross traval		mm	450
Max. distance from spindle center to table		mm	580
Magnetic chuck size		mm	400x1000
Speed of table longitudinal movement		m/min	7-23
Table transverse movement	Auto feed	mm/min	0.1-8
	Rapid speed	mm/min	990
	Feed of handwheel	mm/div.	0.02
Wheelhead vertical movement	Auto feed	mm/stroke	-(H/R mode) 0.005/0.01/0.02/0.03/0.04/0.05(0nly for D model)
	Rapid speed	mm/min	-(H mode) 610 (Only for R model)480 (Only for D model)
	Feed of handwheel	mm/div.	0.005
Grinding wheel	Speed	rpm	50Hz 1450
			60Hz 1750
	Size(ODxWxlD)	mm	350x40x127
Spindle Motor		kw	4/5.5
Hydranlic Motor		kw	2.2
Cooling pump motor		kw	0.09
Elevating Motor		kw	-(H mode) 0.25 (R mode) 0.5 (D mode,servo motor)
Cross feed motor		kw	0.06
Max.loading capacity of table(include magnetic chuck)		kg	600
Total rated power		kw	7.5/9
Gross weight		kg	3900
Package dimensions(LxWxH)		mm	3420x2250x2230

Detailed Photos
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What's the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.

---
