US$2,000.00-3,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
MD618A MD820 MD1022
Type
Surface Grinding Machine
Controlling Mode
Artificial
Cylindrical Grinder Type
Universal Cylindrical Grinder
Certification
CE, RoHS, ISO 9001
Transport Package
Plywood Case
Production Capacity
10 PCS/Month
Product Description
SURFACE GRINDING MACHINE FEATURES:
Product Description:
1 Adopt the exceeding precise class7(P4 level) ball bearing for spindle
2 Bring transmission by synchronous belt, operating simple and convenient
3-axis manual operation, X, Y axis can be eletric auto operation.
High rigidity H-frame column with spindle center to table
Enhanced ribbed full cast iron base
Enlarged spindle housing for heavier grinding
Cartridge w / 4 preloaded class 7 (P4) bearing
Roller steel balls on linear table ways for easy and smooth longitudinal movements.
Double-V saddle ways for rigidity
Manual lubrication system
SPECIFICATIONS:
| MODEL | MD618A |
| Working table | Table Size (L× W) | mm | 460×180 |
| Max movement of working table(L× W) | mm | 500×190 |
| T -Slot number×width | mm | 1×14 |
| Grinding head | Max distance from spindle center to table surface | mm | 335 |
| Wheel Size(Outer diameter×width×Inner diameter) | mm | φ180×13×Φ31.75 |
| Wheel speed | 50HZ | r/min | 2850 |
| 60HZ | | 3440 |
| | Longitudinal speed of working table | m/min | 3-20 |
| Feed amount | Cross feed of working table | Continuously(Variable
Transmission) | mm/min | 150 |
Intermittently(Variable
Transmission) | mm/times | 0-5 |
| Per revolution on handwheel | mm | 2.5 |
| Per graduation on handwheel | mm | 0.02 |
| Vertical feed on handwheel | Per revolution | mm | 1.25 |
| Per graduation | mm | 0.01 |
Commutation
feeder | Total input power | w | 150 |
| X- feeder output speed | R/min | 0-225 |
| X- feeder size | mm | 280×130×120 |
| Y- feeder output speed | R/min | 0-120 |
| Y- feeder size | mm | 280×130×120 |
| Motor power | Spindle motor | kw | 1.1 |
| Coolant pump motor | w | 40 |
| Working precision | The parallelism of working
surface to base level | mm | 300:0.005 |
| Surface roughness | μm | Ra0.32 |
| weight | Net | kg | 667 |
| Gross | kg | 767 |
| Overall dimension(L×W×H) | mm | 1550x1150x1590 |
| Package dimension(L×W×H) | mm | 1000x1150x1760 |
>>
