| US$10,000.00 | 1 Set (MOQ) |
| Model | HTD-1404 |
| Canopy/Cabin | ROPS&Canopy |
| Engine | |
| Engine Power/Speed(HP) | 140/2300 |
| Engine Type | 6 Cylinder,Inline,Water-cooling,4 Strokes,Injection |
| Fuel Tank Capacity(L) | 150 |
| Air Cleaner | Wet/ Dry |
| Transmission | |
| No.of Speed | 24+8Creeper/24+24 Shuttle |
| Main Cluth | Double, Luk Clutch |
| Brake | Hydraulic disc |
| Differential Lock | Meshing Sleeve Type Gear |
| PTO | Independant |
| PTO Speed(rpm) | 540/850/1000 |
| Hydraulics | |
| Steering | Hydraulic Power Steering |
| Hitch category | 3 point linkage, Cat. II or II |
| Behind Valve | 2 Pair of Hydraulic Pool |
| Behind Lift Capacity (KG) | min. 3230 KGS |
| Tires Standard(Front/Rear)(mm) | 13.6-24/16.9-34 |
| Travelling Speed(MAX.)(Km/H) | 54.9 |
| Front /Rear Counter Weight (Kgs) | F 480Kgs/ R 180Kgs |
| Dimension(mm) | 4640*2130*3250 |
| Ground Clearance(mm) | 379 |
| Weight (kg) | 4900 |
| Model | HTD-1604 |
| Canopy/Cabin | AC&Fan Cabin |
| Steering Wheel | Adjustable |
| Engine | |
| Engine Power/Speed(HP) | 160/2300 |
| Engine Type | 6 Cylinder,Inline,Water-cooling,4 Strokes,Injection |
| Fuel Consumption(g/kw.h) | <=258 |
| Fuel Tank Capacity(L) | 180L |
| Air Cleaner | Wet/ Dry |
| Transmission | |
| No.of Speed | 24+8 Creeper/24+24 Shuttle |
| Main Cluth | Double, Luk Clutch |
| Brake | Hydraulic disc |
| Differential Lock | Meshing Sleeve Type Gear |
| PTO | Independant |
| PTO Speed(rpm) | 540/850/1000 |
| Hydraulics | |
| Steering | Hydraulic Power Steering |
| Hitch category | 3 point linkage, Cat. II or II |
| Behind Valve | 3 Pair of Hydraulic Pool |
| Behind Lift Capacity (KG) | min. 3800 KGS |
| Tires Standard(Front/Rear)(mm) | 14.9-26/18.4-38 |
| Travelling Speed(MAX.)(Km/H) | 55 |
| Front /Rear Counter Weight (Kgs) | F 600Kgs/ R 540Kgs |
| Dimension(mm) | 4700*2200*3350 |
| Ground Clearance(mm) | 385 |
| Weight (kg) | 6100 |
| Model | HTD-1004 |
| Canopy/Cabin | ROPS&Canopy |
| Engine | |
| Engine Power/Speed(HP) | 100/2300 |
| Engine Type | 4 Cylinder,Inline,Water-cooling,4 Strokes,Injection |
| Fuel Consumption(g/kw.h) | <=245 |
| Fuel Tank Capacity(L) | 150 |
| Air Cleaner | Wet/ Dry |
| Transmission | |
| No.of Speed | 16+8 Creeper |
| Main Cluth | Double |
| Brake | Hydraulic disc |
| Differential Lock | Meshing Sleeve Type Gear |
| PTO Speed(rpm) | 540/760 or 540/1000 |
| Hydraulics | |
| Steering | Hydraulic Power Steering |
| Hitch category | 3 point linkage, Cat. II or II |
| Behind Valve | Two Pair of Valves |
| Behind Lift Capacity (KG) | 2340 |
| Tires Standard(Front/Rear)(mm) | 13.6-24/16.9-34 |
| Travelling Speed(MAX.)(Km/H) | 54.9 |
| Wheel Base Front/Rear(mm) | 1610/1620 |
| Front /Rear Counter Weight (Kgs) | F 320Kgs/ R 180Kgs |
| Dimension(mm) | 4440*2130*3250 |
| Ground Clearance(mm) | 379 |
| Weight (kg) | 4600 |
