Universal Cold Shrinking Tube for 7/16 DIN Connector

Product Details

Product Description

Product Description
CSK Cold Shrink Coax Sealing Kits contain EPDM rubber sleeves that are applied without heat or flame. Where cable-to-connector diameter ratios dictate the need, foam strips serve as a dimensional spacer between smaller coax cables and the minimum sealing diameter of the cold shrink tubing. The cold shrink tubing assembly serves as an outer seal which seals on the O. D. Of the foam strip or coax cable.The coaxcable seal kit provides a moisture seal when installed on the coax cable/connector combinations listed in the "Application Chart. " It is compatible with thecoaxcablesandN or7/16DIN connectors.
UltimateTensile Strength: 11.8MPa
UtimateElongation: 750%
TearStrength: 38.6N/mm
DielectricStrength: 19.1KV/mm
MoistureAbsorption Weightgain: 1.8% 7days,90°C,H₂O
UVResistance: 2,000hrs,UVB-313 fluorescentlamp,exposure ASTMG-53

---
