Two Platen Injection Machine Z/3000

Product Description

Z Series / Two Platen IMM According to product demand , easy to customize opening stroke Mold opening & clamping with agility and stability , which has improved cycle time Increase the service life and reduce maintenance cost With strong stiffness of frame platen , which can reduce the floor area Open stroken & mold thickness can be increased within permitted / feasible rang The ejector rod can be lenghtened PID temperatureControl of mold hot runner Overlap functiong of plasticizing & charging can be done when in mold open or mold eject stage Specification of clamping & injection unit can be changed flexibly / combination machine can made to order European & American Design Mature Structure Create Core Value for Customers

INTERNATIONAL CLASS NO.	3000/62000
SPECIFICATION	Z/3000
SCREW TYPE	A	B	C
INJECTION UNIT
screw diameter mm	180	210	220
screw L/D ratio L/D	24.8	21	21
shot volume (theoretical) cm3	29390	40003	43904
injection weight(PS) g	26745	36403	39953
injection rate g/s	1469	2000	2195
injection pressure mpa	210	154	140
screw speed rpm	50
CLAMPING UNIT
clamping force kn	30000
space between tie-bars (w*h) mm	2080*1880
max.mould height mm	2100
min. mould height mm	1000
ejector stroke mm	500
ejector force kn	500
max.daylight mm	4200
mould opening stroke mm	3200/2100
max.mold weight t	66
OTHERS
pump max. pressure mpa	21/16
pump motor power (servo) kw	55+55+55+55+7.5
heating power kw	194
numbers of heating area segment	10+1
machine dimension (l*w*h) m	16.5*4.9*5
oiltank cubage l	3600
machine weight ton	165

Company Information
HAILONG GROUP-NINGBO BEILUN ALLWAY MACHINERY CO., LTD.is located in HAILONG industrial park, national developement zone beilun ningbo ,our company is long engaged in the professional manufacture of high precision injection molding machine. we have successively introduced machines with clamping force form 90-3000Ttons as well as more than 20types of special application machines which is leading the market.
Our company has a high qualified team who are specialized in the research and development as well as manufacturing engineering technology for all kinds of injection molding machine for long time. we have created lots of injection molding machneproduct proprietary technology and we have built up quick respinse output mechanism that can offer personalized solutions for our customer based on their requirements. with strong and powerful strength for the technology design and equipment manufacture , our products design has integrated with international advanced technology as well as the indeas of keeping on improving , creation and transcendence.
Based on the powerful strength of the head company HAILONG GROUP ,our company has built a HAILONG machinery intelligent manufacture system.integrated with european technology "WELLISH&"AOTAI" brand several series of export-oriented high end special application injection molding machine are very popular with customers form home and abroad.
Exhibition Show
ALLWAY---ALWAYS ON THE WAY WITH YOU !

---
