Basic Info.
Braking Mode
Front Disc Brake Drum
Cooling Method
Air Cooling
Starting Type
Electric/ Kick
Transport Package
Carton and Iron
Specification
1740*650*1100
Product Description
Product Description
| Engine | single cylinder,4 stroke |
| Clutch method | Automatic clutch |
| Displacement | 48ml |
| Bore & Stroke | 47*41.2 mm |
| Cooling System | Air cooling |
| Compression Ratio | 9.0:1 |
| Fuel feed | 90# |
| Max Power(km/r/min) | 4.4/7500 |
| Max Torque(n.m/r/min) | 6.8/6000 |
| Max Speed | 65 kmph |
| Ground clearance | 110 mm |
| Fuel consumption | 1.3L/100KM |
| Ignition | CDI |
| Fuel tank capacity | 4.0L |
| Starting System | Electric + kick |
| Front Brakes | Drum |
| Rear Brake | Drum |
| Front tires | 16*3.00/ 3.0-12 |
| Rear tires | 16*3.00/ 3.0-12 |
| Dimensions (mm) | 1670*675*1040 |
| Wheel Base | 1170mm |
| Shock absorber | Hydraulically Damped |
| Payload | 130kg |
| Net Weight | 52kg |
| Packing size | 1450*330*760 |
Packaging & Shipping FAQ
1.Q: What's your payment terms?
A:T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages!
2.Q:Can I mix different models in one container?
A:Yes, different models can be mixed up in one full container.
3.Q: What"s the delivering time ?
A: For example,the delivery time is about 20 days ,the bulk delivery time is base on specifications for your order and quantity.
4.Q: How does your factory do regarding the quality control?
A: Quality is priority. We always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before packing and shipping.
Thanks for your visiting!
any questions, pls contact us freely !
>>
