Basic Info.
Application
Construction Wire Mesh, Protecting Mesh, Fence Mesh, Gabion Mesh, Barbecue Wire Mesh, Spring
Wide in Width
0.15-15.0mm
Metal Wire Drawing
Cold Drawing
High Carbon Steel
Pholish
Transport Package
Spool, Coil, Roll
Specification
DIN2078 JIS 32551
Production Capacity
10000
Product Description
We manufacture and provide quality galvanized iron wire (low carbon steel wire) for Redrawing and industrial use, mainly electronic galvanized wire.
1) Specifications: As required
2) Customized orders are also acceptable
Packing: According to our customers' requirements
1.Diameter range:0.15-16.00mm
2.Main application:making spring,mattress,wire rope, brush, cable
3.Standard: GB4357,DIN17223,JIS G 3521 , EN10270-1
Ungalvanized steel wire
Galvanized steel wire
Spring steel wire
Reinforced Steel Wire
Phosphatized Steel Wire
The Raw Material
(45# 60# 65# 62A 72A 65Mn 70# 82A 82B T9A 1008 1006 18A 22A)
Steel Grade
GB Standard |
Carbon
% |
Silicon
% |
Manganese
% |
Phosphorus
% |
Sulphur
% |
Chromium
% |
Nickel
% |
Cuprum
% |
60# |
0.60-0.61 |
0.18-0.22 |
0.52-0.59 |
0.012 |
0.007 |
0.06-0.07 |
0.05 |
0.18 |
65# |
0.65 |
0.21 |
0.56 |
0.013 |
0.008 |
0.05 |
0.04 |
0.14 |
65Mn |
0.60-0.70 |
0.10-0.25 |
0.70-1.00 |
0.030 |
0.030 |
0.20 |
0.20 |
0.25 |
70# |
0.69-0.71 |
0.19-0.21 |
0.53-0.58 |
0.010-0.012 |
0.003-0.006 |
0.01-0.05 |
0.02-0.04 |
0.04 |
72A 72B |
0.72 |
0.19 |
0.71 |
0.013 |
0.006 |
0.02 |
0.02 |
0.03 |
80# |
0.80-0.81 |
0.22-0.24 |
0.59-0.76 |
0.008 |
0.004 |
0.04 |
|
|
82A 82B |
0.82 |
0.24-0.25 |
0.76-0.77 |
0.011-0.014 |
0.004-0.007 |
0.17-0.17 |
|
|
>>
