Shu-04m-021-N2h USB Products

Product Description

Product Description I. Product Overview This product is a USB connector product with a two-piece housing (housing) design with a housing length (L) of 24.7 mm and an internal wire diameter (wire diameter) of 2.2 mm. This design is usually intended to provide a solid connection, convenient data transmission, as well as a certain degree of mechanical protection and electromagnetic shielding. II. Main Features 1. Two-piece shell design: the shell is divided into two parts, may be through the snap, screws or other means of close connection, forming a whole to protect the internal USB interface and wire. This design helps simplify the assembly process while providing the necessary structural support and protection against physical damage. 2. Specific specifications: Housing length 24.7 mm, may be suitable for specific space-constrained application scenarios. The conductor diameter of 2.2 mm ensures adequate current carrying capacity and signal stability while maintaining a degree of flexibility for wiring. 3. Wide compatibility: Despite having a specific housing design and specifications, the product usually still follows the USB standard interface specification, and is therefore compatible with most USB-enabled devices. 4. Data transmission and power supply: Support high-speed data transmission (the specific speed depends on the USB version, such as USB 2.0, USB 3.0, etc.). Provides standard USB power supply function to support device charging and data synchronization. III. Technical Specifications Interface type: USB standard interface (e.g. USB 2.0, USB 3.0, etc.) Case Length: 24.7 mm Lead wire diameter: 2.2 mm Data transfer rate: Depends on the USB version (e.g., USB 3.0 interface has a theoretical transfer rate of up to 5Gbps) Power supply: Supports standard USB power supply specifications (typically 5V DC) Material: Metal or plastic Usage Scenario Due to the specific specifications and design of the product, it may be suitable for application scenarios that require precise control of the interface size and wire diameter, such as embedded systems, industrial control equipment, medical equipment, or special customized electronic devices. V. Conclusion "TWO-Piece housing L=24.7 wire diameter 2.2 USB Products" is a USB connector product with specific specifications and design, its two-piece housing and precisely controlled dimensions make it suitable for a variety of specific application scenarios.
Detailed Photos

---
