US$38,500.00-60,000.00
|
1 Set
(MOQ)
|
Basic Info.
Model NO.
YHZS35 Mobile Concrete Batching/Mixing Plant
Machining Process
Automatic Controlled Production Line
Certification
ISO9001: 2000, CE, Soncap
Aggregate Batcher
PLD1200-2
Controlled Method
Full Automatic Computer Control
PLC
Omron or Siemens Make
Aggregate Belt
Belt Conveyor Type
Cement Silo
50/100t Bolted Type
Power Source
380V, 50Hz, 3 Phase
Name
Yhzs35 35m3/H Mobile Concrete Batching/Mixing Plan
Transport Package
Standard Packing for International Transport
Specification
ISO9001: 2008
Production Capacity
20 Sets Per Month
Product Description
Yhzs35 35m3/H Mobile Concrete Batching/Mixing Plant Price
Sizes of FOCUS Portable Concrete Batching Plant, Mobile Concrete Mixing Plant:
YHZS25 25m3/h, YHZS35 35m3/h, YHZS50/60 50-60m3/h, YHZS75 75m3/h
Movable/ portable/ trailing/ pulling concrete batching/mixing plant.
Main features of FOCUS RMC Mobile Concrete Batching/Mixing Plant:
1.Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this mobile rmc concrete plant.
2.Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, auto control system with control panel provides ease of use as well as storing, editing and retrieving of up to 20 recipes for the proportioning of different materials;
Twin-shaft mixer offers this mobile concrete plant a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3.Highly precise dosing of water, cement, fly-ash, additive
Focus mobile concrete plant dosing is realized by three-point suspension sensors, and they are all metered separately.
4.Optimized and modular design
Yhzs35 35m3/H Mobile Concrete Batching/Mixing Plant Price
| Model | YHZS25 | YHZS35 | YHZS50/60 | YHZS75 |
| Output capacity | 25³/h | 35³/h | 50³-60³/h | 75³/h |
| Overall power | 40kw | 60kw | 85kw | 105kw |
| Discharge height | 3800mm |
| Max. hauling speed | 40km/h |
| warranty | 13months after commissioning |
| After-sale service | Guidance on erecting, commissioning and operator training, 24/7 technical assistance afterwards |
| Concrete mixer | JS500 | JS750 | JS1000 | JS1500 |
| Motor power | 18.5kw | 30kw | 18.5kwX2 | 30kwX2 |
| Max. aggregate dia. | 80mm |
| Aggregate batcher | PLD800 | PLD1200 | PLD1600 | PLD2400 |
| Aggregate weighing precision | ±2% |
| Aggregate feeder | Belt conveyor |
| Other scale scope | Cement | ±1% |
| water | ±1% |
| additive | ±1% |
| Control system | Auto computer control, 1 set |
| Pneumatic system | 1 set |
FOCUS mobile concrete plant is convenient either for container transport or for towing vehicles.
>>
