Huazheng Electronic's product capability platform enable complete vertical integration from concept design, initial design, production validation, mass production to value-added services. |
| Overall Capability | Product Range: Standard and customized high temperature and high power cable |
| Temperature Range: From -100 degree Celsius to 450 degree Celsius |
| Voltage Range: from 30V up to 50KV |
| Minimum Wall Thickness:0.0375mm |
| Conductor Size Range: From 40AWG to 200mm2 |
| Core wire: From single core to 50 core wires inside jacket |
| Conductor and Braiding Material | 1. Bare Copper |
| 2. Tin-plated Copper |
| 3. Overcoat Copper - Tinned copper strands covered by tin coating |
| 4. Top coated Copper - Bare copper strands covered by tin coating |
| 5. Silver-plated Copper - Silver plated to copper strands |
| 6. Nickel-plated Copper -Nickel plated to copper strands |
| 7. Hybrid conductor construction |
| 8. Tinsel conductor |
| 9. Carbon Fiber, glass fiber yarn |
| 10. Other specialty conductors |
| Insulation Material | 1. PTFE, PFA, ETFE, FEP |
| 2. Silicone Rubber |
| 3. PVC, XLPVC |
| 4. PE, FRPE, XLPE, TPE, TPU |
| 5. Fiberglass yarn, Mica Tape |
| 6. Other specialty compounds |
| Manufacturing Process | Copper Stranding, Wire Extrusion, Core Wire Cabling, Braiding, Wrapping, Jacket Extrusion |
| Most-used UL cable | UL1330,UL1332,UL1727,UL10086,UL10109,UL4389,UL3266,UL3321, UL3289, UL3132,UL3133, UL3577,UL10198,UL10070, UL1015,UL10269,UL2517,UL2586,UL3280,UL10236,UL3579 |
Packaging & Shipping 1.inner packing: PE bag.(Polybag/header card;Col Sleeve) 2. outer packing: Standard export carton. 3.Delivery Time: 15-30 Working days after receipt the payment. 4.Shipping port: Ningbo/Shanghai China. 5.Shipping cost are quoted under your requirements. Remark 1) We can make sample production according to your drawings and specifications, so please feel free to contact us for samples.
2) If possible, please provide us a drawing or specification table for any product so that we can greatly improve our work efficiency and save your time and energy.
3) OEM Available.
4) Don't hesitate to contact us for any questions of your concern.We'll reply you within 24 hours.
