| Model | unit | CK6160 | CK6150 | CK6140 | |
| Max swing over bed | mm | Φ600 | Φ500 | Φ400 | |
| Max swing over cross slide | mm | Φ395 | Φ250 | Φ240 | |
| Distance between centers | mm | 1500 | 850 | 500 | |
| Spindle bore | mm | Φ82/130 | Φ82 | Φ48/Φ82 | |
| Bar capacity | mm | φ80/128 | 65 | Φ40/Φ65 | |
| Spindle nose | A2-8 | A2-8 | A2-6 | ||
| Chuck size | mm | φ250 | 250 | 200/250 | |
| Spindle speed | rpm | 1600 | 1800 | 2000/1800 | |
| Tailstock quill diameter | mm | φ75 | φ75 | Φ60 | |
| Quill taper | No | MT5# | MT5# | MT4 | |
| Quill travel | mm | 200 | 200 | 100 | |
| Electric tool post | station | 4 | 4 | 4 | |
| Tool size | mm | 25×25 | 25×25 | 20x20 | |
| X/Z rapid speed | m/min | 8/10 | 8/10 | 8/10 | |
| X travel | mm | 320 | 300 | 280 | |
| Z travel | mm | 1600 | 1000 | 750 | |
| Spindle motor | KW | 7.5 | 7.5 | 5.5/7.5 | |
| weight | Kg | 2870 | 2850 | 1800 | |
| dimension | mm | 3150×1650×1750 | 2750X1700X1820 | 2200x1160x1620 | |
| testing | Standard tolerance |
| Periodicity of spindle axial movement | 0.005 |
| Radial run-out for Spindle chuck positioning cone | 0.005 |
| Positional accuracy | ±0.005 |
| Diameter consistency | 0.01/150 |
| planeness | 0.025/φ300 |
| Thread pitch accumulated error | 0.010/100 |
| Surface roughness | Ra1.6μm |
| Standard accessories |
| CNC controller GSK980TDC |
| 4 station turret |
| Manual tailstock |
| high-frequency hardening guideway |
| Auto lubrication |
| Manual 3 jaw chuck |
| Coolant pump |
