SM-450T High Speed Energy Saving Servo High Quality PVC Tubes Basket Pet Preform Injection Molding Machine

Product Description

K&E Machinery (Ningbo) Co., Ltd. presents the SM-450T High Speed Energy Saving Servo Injection Molding Machine. This high-quality machine is perfect for producing plastic products such as PVC tubes, fruit and vegetable baskets, and pet preforms. With its advanced technology and energy-saving features, it is an excellent choice for any injection molding needs.
Parameters:

SPECIFICATION		SM-450
SCREW TYPE		A	B	C
Injection Unit
Screw diameter	mm	70	75	80
Screw L/D ratio	L/D	21.4	20	18.8
Shot volume(theoretical)	CM3	1347	1657	1885
Injection weight(PS)	g	1226	1508	1715
Injection rate	g/s	337	414	471
Injection pressure	Bar	2140	1864	1639
Screw speed	rpm	190
Clamping Unit
Clamping force	KN	4500
Open stroke	mm	764
Space between tie-bars(W*H)	mm	780*730
Max mould height	mm	780
Min mould height	mm	300
Ejector stroke	mm	200
Ejector force	KN	110
Others
Max pump pressure	Bar	16
Motor pump power	Kw	55.4
Heating power	Kw	23.2
Machine dimension(L*W*H)	M	7.48*1.9*2.1
Oil tank cubage	L	600
Machine weight	Ton	16.8

Product Description Introducing the SM-450T High Speed Energy Saving Servo High Quality PVC Tubes Fruit Vegetable Basket Pet Preform Injection Molding Machine by K&E Machinery (Ningbo) Co., Ltd. This preform injection machine is perfect for producing plastic products such as PVC tubes, fruit and vegetable baskets, and pet preforms. With its energy-saving servo technology, it ensures efficient and high-speed injection molding. The machine comes with a 12-month warranty and offers engineer installation and debugging services. Get this top-quality injection molding machine for your plastic production needs.

Items		Brand/country
Servo System	Controller	TECHMATION -8' (TAIWAN )
	Servo Motor	INOVANCE (CHINA)
	Servo Drive	INOVANCE (CHINA)
	Oil Pump	ECKERLE (Germany) or SUMITOMO (JAPAN )
Electric Unit	Stroke transducer	NOVO or FLTCH (Germany)
	Breaker	Schneider (France ) or LS (Korea )
	Contactor	Schneider (France ) or LS (Korea )
	Air Switch	Schneider (France )
	Location /Speed Sensor	Schneider (France )
Hydraulic Unit	Hydraulic Direction Valve	YUKEN (Japan)
	Proportion back-pressure valve	North man (Taiwan)
	Plasticizing hydraulic Motor	DAN DUN (ITALY)
	Hydraulic Hose	MANULI(ITALY) or GOOD YEAR (USA)
	Hydraulic Sealing ring	All Italy and Japan
Others Unit	Mechanical safety	Standard
	Electric safety	Standard
	Mold close fast	Standard
	Injection Unit	Linear guide-way
	Air core	1pcs
	Hydraulic Core	1pcs
	T slots and screw holes	Standard
Servo system Compared with the other manufacturers is big, Overload ability strong and stable.

---
