US$10,000.00-75,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Making Method of Parison
Injection Blowing
Computerized
Non-Computerized
Certification
CE, ISO9001:2008
Application
Plastic Bottle
After Service
Engineers Available to Service Machinery Oversea
Warranty
1 Years Warranty
Bottle Material
Pet,PP,PC,PS,PMMA,Tritan
Other Service
" Turn-Key "Projects
Transport Package
Wooden Package
Specification
4.5x1.7x3.3m
Production Capacity
100PCS/Month
Product Description
JASU Factory One Step INJECTION STRETCH BLOW
MOLDING MACHINE IB 1100-2
| IB1100-2 Main Specification | Main Devices Brand |
| Material | PC,PP,PET,TRITAN,PMMA,PS | Servo Motor and Oil Pump | Phase (Italy) and Eckerle (Germany) |
| Screw Diameter | 50mm | Sealing Parts | Yuken(Japan), TAIWAN |
| Screw L/D Ratio | 20.5:1 | Hydraulic Valve | Yuken(Japan), TAIWAN |
| Screw Speed | 0-150 | Air Valve | AirTAC |
| Theoretical Injection cavity | 481cm3 | Air Cylinder | AirTAC |
| Injection Pressure | 176Mp | Controller (PC) | JASU, TAIWAN |
| Max.hydraulic Pressure | 140kg/cm | Photosensor | Carlo,China |
| The actual injection quantity | 425g(ps),16Oz | Safety delay | Schneider (ShangHai |
| Screw Stroke | 245mm | Servo Motor for Turntable | TECO, Taiwan |
| Blow Clamping Force | 150kn | Gear Reducer | SESAME, Taiwan |
| Clamp Tonnage | 600kn | Low-voltage components | Joint Venture |
| Wheel Diameter | 1100mm | Hydraulic hose | China |
| Max.Height Of Bottle | With core:20-300mm | F.R.L | China |
| Open Vertical Mode Trip | 530mm | Hydraulic joint | China |
| Max.Pump Pressure | 16Mpa | Blowing valve | AirTAC(TaiWan) |
| Servo Motor | 22kw | Low-pressure cylinder | AirTAC(TaiWan) |
| Electric power | 12.2kw | low-pressure valve | AirTAC(TaiWan) |
| Tank volume | 400L | PLC | JASU(TaiWan |
| Dimension of Machine | 4.5*1.7*3.3m | Air switch | Schneider(Shanghai) |
| Machine Weight | 7.5T | Display screen | JASU(TaiWan) |
Mould and tooling, we have mould workshop ourselves, advanced CNC machine and smart design engineers,we can treat different material and
size products from different customers over the world.
Auxiliary machine,we will equip you with the necessary quality auxiliary machines to ensure the production plan running well,we can supply you
one-stop service.
Jasu injection stretch blowing mould
JASU injection blow molding machine advantage:
1)Electrical motor and pneumatic drive,avoid hydraulic dirty product.
2) Full automatic control ,easy operation.
3) material barrel and hot runner temperature control accurately.
4) save more cost than traditional machine.
5) compact structure.
6) Injection:
Hot runner and temperature control device and standard configuration only change mold to make a new product.
Blow:
Hydraulic mold clamping,core insert,blow and bottom molding are standard configuration.
Product release :Ejector is a standard device
Gauangzhou Jasu Precision Machinery Co.Ltd is a sabusidiary of JASU International Machinery Group locates in
Guangzhou China, which is top 3 supplier of CNC machine tools in South China. JASU owns R&D center and factories in
Guangzhou and Suzhou. JASU has been dedicated to manufacturing CNC lathe, machining center, Gantry CNC milling
machine and machine tool accessories for 20 years.
Absorbing the design and manufacture of Taiwan and Germany, JASU create a series of highly distinctive, automatic and
cost-effective CNC Machine Tools, machine accessory and one step Injection (Stretch) Blow Molding Machine. JASU has got
high reputation and trust among customers by means of modern management method, perfect quality, novel design and
reasonable price.
Our company faith is "better and faster, it is JASU". We are engaged in providing machines with high quality and best service
to create benefit for enterprise and create value for customer.
JASU group
FAQ:
Q1: All of your products are made by your self or compacted via purchasing the others?
A1: We have independent technical team who focus on making machines; all the products are made by our technical team.
Q2: What is the ability of your factory?
A2: About blow molding machine, we could produce 30 sets machine per month
Q3: Do you have any technical supports about your products?
A3: We have had long term collaboration with German, and we have a lot of cooperation with a lot of advanced manufacture company on the world.
Q4: Do you have any other service about your products?
A4: We have a lot of experience on making complete "Turn-Key" projects and specifications for our clients. Also we have a fixed service system
Q5: How do you make the quotation for clients?
A5: The price depends on quality and performance but the clients should be satisfied us at first
>>
