Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
Rack Mounting the Chassis Refer to Figure 2‐8 or Figure 2‐9 and proceed as follows to install the chassis into a 19‐inch (48.3‐cm) rack: 1. Position the chassis between the vertical rails and align the mounting holes in the chassis brackets with those in the rack frame. 2. Fasten the chassis securely to the rails using the customer‐supplied mounting screws (four for the STK‐RPS‐150CH2, ten for the STK‐RPS‐150CH8). Figure 2-8 Fastening the STK-RPS-150CH2 to the Rack 1 STK-RPS-150CH2 chassis 3 Mounting screws 2 Rails of 19-inch rack Installing and Connecting a Redundant Power System 2-16 Installation Figure 2-9 Fastening the STK-RPS-150CH8 to the Rack Connecting the RPS Cable and AC Power Cord The redundant power supply is connected to the A4 switch using an RPS cable. To connect a redundant power supply, proceed as follows: 1. Using a Phillips screwdriver, remove the cover from the redundant power supply connector on the A4 switch. 2. Connect one end of the RPS cable to the redundant power supply connector on the A4 switch. Then connect the other end of the cable to the redundant power supply connector at the rear of the RPS as shown in Figure 2‐10. 3. Connect the AC power cord to the AC input power connector on the RPS shown in Figure 2‐11, then plug the AC power cord into the main AC power outlet. The green Power LED on the front of the RPS will illuminate to indicate a successful connection. If the LED remains off, proceed as follows: a. Check the AC power cord connection at the AC power source and make sure the power source is within specification. b. Check the AC power connection to the RPS. c. Swap the AC power cord with a known good one. d. If the green LED continues to remain off, contact Enterasys Networks. Refer to “Getting Help” on page xvii for instructions. Otherwise, proceed to step 4. 1 STK-RPS-150CH8 chassis 3 Mounting screws 2 Rails of 19-inch rack Installing and Connecting a Redundant Power System Enterasys A4 Fast Ethernet Switch Hardware Installation Guide 2-17 . Figure 2-10 Power Connectors on STK-RPS-150PS (rear view) Figure 2-11 STK-RPS-150PS RPS Cable and AC Power Cord Connections
>>
