| US$15,500.00-19,500.00 | 1 Piece (MOQ) |
| Model | NA-510L |
| Table size | 1500mm*3000mm |
| Max. working stroke | 1600mm*3100mm |
| Working height | 200mm |
| X & Y Rapid speed | 80m/min |
| Z & W rapid speed | 20m/min |
| Vacuum pump | 7.5KW / 250m3/h |
| Dimensions | 3500mm*2200mm*2100mm |
| Net weight | 3500 kgs |
| Spindle speed | 24000rpm |
| Spindle | 9KW / air cooling |
| Controller | Taiwan Syntec / Taiwan LNC control system |
| Motor | Servo motor / Delta servo motor |
| Rail | Taiwan linear rail |
| Rack | Helical racks |
| Table design | Vacuum table / PVC table |
| ATC | Linear type / 16 positions |
| Positioning cylinder | 3 pcs + 2 pcs. |
| Tool holder | ISO-30 |
| Package | Plywood box |
| software | type 3/ ArtCAM |
