| SPECIFICATIONS |
| RANGE OF OPERATION | Boom length | 3680-4000mm |
| Arm length | 1850-2650mm |
| Max radius of capture | 7000-7800mm |
| Grab the biggest opening width | 1250mm |
| Grab the minimum opening width | 80mm |
| Maximum radius weight capacity | 500-700kg |
| Grapple rotation angel | 360° |
| Maximum Dumping height | 4650-5100mm |
| Back-End radius of gyration | 1980mm |
| Max lifting height of cab | 80~18000mm |
| Max extended distance of arm | 800mm |
| DIMENSION | (Length*width*height) travel position | 6450*2330*3050mm |
| Wheel base | 2430mm |
| Track(Front/rear) | 1850mm/1750mm |
| Ground clearance of counterweight | 1160mm |
| Min ground clearance | 200mm |
| TECHNICAL PARAMETERS | Angle of rotation | 360° |
| Machine weight | 8300kg |
| Engine model | YUCHAI/YUNNEI |
| Rated Power | 62.5KW/65KW |
| Rated Speed | 2200r/min |
| Hydraulic system working pressure | 21Mpa |
| Hydraulic system flow | 150L/min |
| Variable piston pump | 72ml/r |
| Max Hauling force | 45KN |
| Walking speed | 25km/h |
| Grade Climbing ability | 58%/30° |
| Tyre model | 8.25-16 |
| Volume Of Bucket | 0.35m3 |
| Revolution Overdrive Pressure | 20Mpa |
| Full circle swinging time | 5.5s |
| Fqt Fuel Quantity | ≥6L/h |
| Hydraulic Tank Capacity | 110L |
| Capacity Of The Fuel Tank | 110L |
