Basic Info.
Type
Injection Blow Molding
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Computerized
Computerized
Certification
ISO9001:2008
Maintenance
Whole Life Time
Installation
by Our Engineer
Transport Package
Export Standard Packing, Wood Case
Production Capacity
90-160
Packaging & Delivery
Package Size
6000.00cm * 1800.00cm * 2000.00cm
Package Gross Weight
12000.000kg
Product Description
Plastic Injection Machine Servo Motor Control
pvc injection machine
Specification for 120t :
| Item | Unit | MWK-120 |
| Injection device | Screw diameter | mm | 40 | 42 | 45 |
| L:D | L/D | 20 | 19 | 17.8 |
| Theoretical injection volume | cm3 | 182 | 201 | 233 |
| Injection weight | g | 164 | 181 | 210 |
| Injection rate | g/s | 80 | 86 | 105 |
| Plasticing pressure | g/s | 14.6 | 17.8 | 20.9 |
| Injection pressure | Mpa | 168 | 152 | 140 |
| Screw speed | rpm | 0-200 |
| Mold locking device | Clamping force | KN | 1200 |
| Injection stroke | mm | 155 |
| Die shifting stroke | mm | 320 |
| Tie rod spacing (W x H) | mm | 385×350 |
| Die thickness | mm | 150-400 |
| Ejection stroke | mm | 75 |
| Ejection force | KN | 33 |
| Other | Max. oil pump pressure | Mpa | 16 |
| Oil pump motor power | kw | 11 |
| Electrothermal power | kw | 6.2 |
| Overall dimension (L x W x H) | m | 4.0×1.25×1.75 |
| Machine weight | t | 3.3 |
01 WHY CHOOSE MENGKWA?
1) Mechanical and electric parts of machines for our machines are from famous brands with reliable and stable quality .
2) Machine structures and applicant parts are heavy duty type .
3) Technologies of machines are developing to be much more energy saving and higher production output .
4) Engineers for installation and training are both available in China and abroad .
5) Our after service is available in 24hours by team group to every customer .
6) Our machines reach to 54 countries all over the world since 1996 .
02 TERMS OF PAYMENT
30% deposit and 70% balance before shipment after machine testing approved by customer .
03 PACKING AND LOADING
Safe packing for container loading OR heavy duty iron frame fixing OR wood cases packages .
04 AFTER-SALE SERVICE
1) 24 hours technical support by email, call, video.
2) Warranty for one year after 12 months of shipment.
3) Installation and commissioning engineer will provide the tech long machine, and machine operation of the buyer's personnel on-site training, troubleshooting and machine maintenance. The factory offers free installation training for a week the company engineers, beyond a week, the salaries borne by the customer engineer the factory.
>>
