Automatic Hydraulic Surface Grinding Machine My1230

US$3,000.00-4,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

MY1230

Abrasives

Grinding Wheel

Controlling Mode

Artificial

Automatic Grade

Automatic

Cylindrical Grinder Type

Universal Cylindrical Grinder

Precision

High Precision

Certification

GS, CE

Condition

New

Table Size (Lxw)

750X300

Table Travel

780X320

Spindle Motor

2.2kw

Transport Package

Wood Case

Specification

CE ISO9001

Trademark

L&T

Origin

Tengzhou China

HS Code

84592900

Production Capacity

200PCS/Month

Product Description

Automatic Hydraulic Surface Grinding Machine MY1230
Feature :
1,Compact structure and easy operate.
2,Table longitudinal movement by hydraulic.
3,Table transverse feed by automation operate or by handle.
4,Grinding head vertical move can be adopted with power rapid movement or hand micro feed.
Technical Parameter :

Model	Units	MY1230
Table Size (L×W)	mm	750×300
table travel	mm	780x320
speed of working table	m/min	3-20
Distance From Spindle to table	mm	530
Table Slide way	/	Double V-type rail
V-type rail with Steel-ball	kg	250
Number of T -Slot	mm*n	14*1
Cross Feed On Handwheel	mm	0.02/Gra 4/rev
Vertical Feed On Handwheel	mm	0.01/Gra 2/rev
Wheel Size	mm	2502576.2
wheel Speeds	rpm	2450
Spindle Motor	kw	2.2
Hydraulic station motor	kw	2.2
Rapid Up and down Motor	w	120
Working Pressure	Mpa	4
Max.Capacity	L/min	20
Fuel tank capacity	L	80
Packing Size	mm	196016402020
Net,Gross/weight	kg	1400/1530

Standard Accessories:

Wheel flange	Tool box and tools
Balancing arbor	Balance stand
Wheel exactor	Leveling wedge and bolt
Coolant tank	Wheel dresser stand
Working lamp

Optional Accessories:

Electro magnetic chuck	Cooling and dust collector
Balancing stand	Parallel wheel dresser
