| US$14,930.00 | 1 Piece (MOQ) |
| No. | Item | Unit | Specifications | |||||
| 1 | Type | / | 4LZ-6.0B1 | |||||
| 2 | Structure mode | / | Full feeding, crawler type, self-propelled | |||||
| 3 | Engine | Manufacturing company | / | CHANGCHAI COMPANY,LIMITED | ||||
| | | Engine type | / | 4C6-100 | ||||
| Structure mode | / | Vertical, inline, water-cooled,4 strokes | ||||||
| Rated power | kW | 75 | ||||||
| Rated speed | r/min | 2400 | ||||||
| 4 | dimensions (length×width× height) | At work | mm | 5980×2660×2855(rape combine) | ||||
| In transportation | 5980×2660×2855(rape combine) | |||||||
| 5 | Mass of the whole machine | kg | 3760 | |||||
| 6 | Cutting width | mm | 2000 | |||||
| 7 | Feed rate | kg/s | 6.0 | |||||
| 8 | Minimum ground clearance | mm | ≥315 | |||||
| 9 | Theoretical travel speed | km/h | 2.15~5.28/0~8.7(HST) | |||||
| 10 | Pure field capacity | hm²/h | 0.3~0.5 | |||||
| 11 | Fuel comsumption unit area | kg/hm² | 21~27 | |||||
| 12 | Type of cutter | / | standard II | |||||
| 13 | Type header auger | / | Spiral toothed | |||||
| 14 | Reel | Type | / | Eccentric, spring toothed | ||||
| Diameter | mm | φ900 | ||||||
| No. of bars | | 5 | ||||||
| 15 | Threshing cylinder | No. | | 1 | ||||
| Type | Main cylinder | / | Axial-flow, rasp-bar | |||||
| Auxiliary cylinder | / | / | ||||||
| dimensions (diameter× length) | Main cylinder | mm | φ620×2200 | |||||
| Auxiliary cylinder | / | |||||||
| 16 | Cancave type | / | grid | |||||
| 17 | Fan | Type | / | Centrifugal, volute | ||||
| Diameter | mm | φ400 | ||||||
| No. | | 1 | ||||||
| 18 | Track | Specification (pitch×no. of teeth×width) | / | 90 mm× 53×450mm | ||||
| Distance between tracks | mm | 1250 | ||||||
| 19 | Tyre specification | Guiding wheel | / | / | ||||
| Driving wheel | / | / | ||||||
| 20 | Minimum radius of pass-by | Turn left | mm | 3300/ 3450(rape combine) | ||||
| Turnright | 3500/ 3700(rape combine) | |||||||
| 21 | Type of gear box | / | (HST) hydraulic stepless speed changes or mechanical gear box | |||||
| 22 | Brake type | / | Friction-type hand braking | |||||
| 23 | Type of stalk cutter | / | / | |||||
| 24 | Re-thresher type | / | Plank-tooth | |||||
| 25 | Unloading | / | 360degree auger unloading | |||||
| 26 | Steering mode | Hydraulic power steering | ||||||
