Zenith High Quality Cone Crusher with Capacity 50-350tph

Product Description

Zenith high quality Cone Crusher with Capacity 50-350TPH
Shanghai Zenith cone crushers are the best available choice for the aggregate and mining market. Cone Crushers feature a unique combination of crusher speed, throw and cavity design. With these benefits, our cone crushers provide unbeatable performance in primary or secondary application.
Cone Crusher Features:
1. High quality and productivity
2. Short downtime
3. Easy maintenance, low expense
4. Unparalleled in medium and fine crushing
Cone crusher Advantages:
1. Our cone crushers perform well in crushing various kinds of ores and rocks of medium or above medium hardness. It has the advantages of stable structure, high efficiency and long lifetime. Because we adopt energy saving technologies, the cone crushers consume less energy compared with other brands. Our particular design ensures continuous operation.
2. Due to easy to operate, our cone crusher can be easily integrated to automation system, as a result the overall efficiency can be increased dramatically.
3. The spring safety system of cone crusher acts as an overloading protection system that allows metals to pass through the crushing chamber so as not to damage the cone crusher. The safety system uses dry oil and water as two kinds of sealed formation to make plaster powder and engine oil separated to make sure reliable performance. So the life time of cone crusher is longer, and then the whole cost is reduced.
4. Our cone crusher is suitable to crush medium size, fine and ultrafine powders depending on the different type.
Cone crusher Parameters:

Model	Movable Cone Diametermm (inch)	Chamber Style	Opening Side	Closed Side	Discharging Opening (mm)	REV (r/min)	Power (kw)	Motor Model	Capacity (t/h)	Machine Size (mm)
			Max.Feeding (mm)
36(3′)	900 (3′)	medium	83	102	9-22	580	6-75	Y315S-6/75	45-91	2821×1880 ×2164
		coarse	159	175	13-38				59-163
36(3′)	914 (3′)	fine	13	41	3-13	580	6-75	Y315S-6/75	27-90	2821×1880 ×2410
		medium	33	60	3-16				27-100
		coarse	51	76	6-19				65-140
51(4.25′)	1295 (4 1/4′)	fine	109	137	13-31	485	6-185	Y355M2-6/185	109-181	2800×2342 ×2668
		medium	188	210	16-31				132-253
		coarse	216	241	19-51				172-349
51(4.25′)	1295 (4 1/4′)	fine	29	64	3-16	485	6-160	Y355M1-6/160	36-163	2800×2342 ×2668
		medium	54	89	6-16				82-163
		coarse	70	105	10-25				109-227
66(5.5′)	1650 (5 1/2′)	fine	188	209	16-38	485	6-240		181-327	3911×2870 ×3771
		medium	213	241	22-51				258-417
		coarse	241	268	25-64				299-635
66(5.5′)	1650 (5 1/2′)	fine	35	70	5-13	485	6-240		90-209	3917×2870 ×3771
		medium	54	89	6-19				136-281
		coarse	98	133	10-25				190-336
84(7′)	2134 (7′)	fine	253	278	19-38	435	6-400		381-726	5200×4300 ×4700
		medium	303	334	25-51				608-998
		coarse	334	369	31-64				870-1400
84(7′)	2134 (7′)	fine	51	105	5-16	435	6-400		190-408	5200×4300 ×4700
		medium	95	133	10-19				354-508
		coarse	127	178	13-25				454-599

---
