| US$3,988.00-15,898.00 | 1 Set (MOQ) |
| Specification | Unit | X5750 | X5750A |
| Table size | mm | 500x1600 | 500x2000 |
| T-slots(No./width/pitch) | mm | 5/18/80 | |
| Table travel(X/Y/Z) | mm | 1200/700/500 | 1400/700/500 |
| Swivel angle of milling head | - | 360° | |
| Spindle taper | - | ISO50 | |
| Spindle speed range | r.p.m | (27)30-2050 | |
| Table feed(X/Y/Z) | mm/min | 10-1000/10-1000/5-500 | |
| Table rapid speed | 2200/2200/1100 | ||
| Distance between spindle nose and table surface | mm | 50-550 | |
| Distance from spindle center line to column | mm | 45-745 | |
| Main motor power | kw | 7.5 | |
| Feed motor | kw | AC servo motor X/Y:18NM;Z:27NM | |
| Max load | kg | 1800 | |
| Overall size | mm | 2625x2460x2080 | 2625x2860x2080 |
| Weight | kg | 4200 | 4500 |
