Vmc1890 CNC Vertical Machining Center 24 Tools Disc Type CNC Milling Machine

Product Description

Product Description
Products Description:
VMC1890 CNC vertical machining center 24 tools disc type CNC milling machine
Main configuration & accessories:
1. Resin sand casting, Meehanite HT-300;
3. X, Y, Z rails adopt stainless steel telescopic cover;
4. Roller type linear guideway from Taiwan
5. Ball lead screw from Taiwan
6. Standard with belt driven spindle, optional for direct driven spindle;
7. Taiwan pneumatic cylinder;
8. Taiwan ATC, umbrella type and disc type are available;
9. Import bearings for leadsrews;
10. Import coupling;
11. Headstock Nitrogen balance system as option;
12. Full enclosed cover;
13. Rigid tapping;
14. Spindle center ring blast;
15. Work lamp;
16. Pilot lamp;
17. USB and Internet interface;
18. Manual pulse generator (MPG);
19. Centralized automatic lubrication system.
20. Cooling system.
21. Heat exchanger for electrical cabinet ;
22. Leveling blocks & bolts;
23. Toolbox and tools;
24. CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.
Technical parameter:

Item	Unit	VMC1890
Capacity
X axis travel	mm	1800
Y axis travel	mm	900
Z axis travel	mm	800
Spindle nose to worktable	mm	150-950
Spindle center to column	mm	965
Leadscrew size
Leadscrew diameter	mm	Φ55
Linear guideway width	mm	55/55/55
Worktable size
Worktable Length	mm	2000
Worktable width	mm	900
Max loading capacity	kg	2000
Spindle
Spindle speed	rpm	6000
Main motor power	kw	15/18.5
Spindle taper		BT50
Feeding system
Fast moving speed (X/Y/Z)	m/min	30/30/30
Cutting speed	mm/min	1-10000
Feed motor power	kw	3.5 *3.5 *4.5
Tool Magazine
Capacity	pcs	Arm 24
Max tool diameter	mm	120
Max tool weight	kg	8
Max tool length	mm	300
Accuracy
Positioning accuracy	mm	0.012
Repeat accuracy	mm	0.008
Machine dimensions
Length	mm	5100
Width	mm	3800
Height	mm	3500
Weight	kg	15500

Standard Accessories:
Fanuc 0i-MF(5) control system
Taiwan Spindle: 8000rpm
X/Y/Z axes: Fanuc servo drive motor
Main motor: Fanuc spindle motor
24 tools Disc type
USB for information transfer
Rough cutting of thread
Full closed cover
Automatic lubrication
Coolant system,
work lamp,
Tri-color indication lamp,
Air gun,
Heat exchanger in cabinet,
3-Axis linear guideway from Taiwan Hiwin,
Ball leadscrew from taiwan Hiwin,
Optional accessories:
Automatic chip conveyor & chip bucket (Chain type)
Automatic chip conveyor & chip bucket (Screw type)
Spindle direct driven, speed 12000 rpm
Spindle oil cooling
Spindle center water spray
Nitrogen balance cylinder
Air conditioner for electricity cabinet
4th Axis or 5th Axis Company Profile
