| US$22,800.00-38,800.00 | 1 set (MOQ) |
| Model | KWP-800 |
| Max. Diameter Of Unwinding Roll (Mm) | 1200mm |
| Max. Fabric Roll Width(Mm) | 800mm |
| Max Printing Width(Mm) | 700mm |
| Thickness of Plate(Mm) | 3.5-4.5mm |
| Max. Printing Speed | 80pcs/min |
| Heating Dry Oven Unit | 2pcs |
| Gross Power | 40kw |
| Installing Dimensions (L*W*H)(Mm) | 12000*2000*1800mm |
| Weight (Kg) | 6000kgs |
| Model | KWP-1300 |
| Max. Diameter Of Unwinding Roll (Mm) | 1200mm |
| Max. Fabric Roll Width(Mm) | 1300mm |
| Max Printing Width(Mm) | 1200mm |
| Thickness of Plate(Mm) | 3.5-4.5mm |
| Max. Printing Speed | 70pcs/min |
| Heating Dry Oven Unit | 2pcs |
| Gross Power | 40kw |
| Installing Dimensions (L*W*H)(Mm) | 12000*2300*1800mm |
| Weight (Kg) | 7500kgs |
No. | Position | Name of main parts | Spec./type | Qty | Remarks |
1 | Unwinder of base fabric | Run over shelf | 1 | ,. The unwinder is equipped with automatic deviation rectification device. Unique pneumatic scroll mode is very convenient to use. EPC | |
EPC | 1 | ||||
Scroll cylinder | 100×500 | 2 | |||
Unwinder shaft | 2 | ||||
| Inverter | 1.5kw | 1 | |||
Reducing speed motor | 1.5kw | 1 | |||
SERVO MOTOR | 4.4kw | 1 | |||
| 2 | Printing system | Ink rubber roller | 4/5/6 | PLC, controls the run of complete machine. When stop, ink distribution motor will work automatically and keep the degree of uniformity of printing ink. When start this machine again, the production rejects can be reduced. It is very convenient for automatic circulating system of printing ink to control the concentration and degree of uniformity of printing ink. The overprinting accuracy of printing system will be 40 mm at transverse direction and 3600 without stop. The speed is controlled by transducer | |
Anilox roll | 4/5/6 | ||||
| Printing plate roller | 4/5/6 | ||||
Impression steel cylinder | φ132×850 | 4/5/6 | |||
Ink distribution motor | 9TDY060-7 | 4/5/6 | |||
Automatic circulating system of printing ink | pneumatic diaphragm pump | 4/5/6 | |||
Transverse aiming at plate without stop | 4/5/6 | ||||
Servo Motor | 1.57kw | 4/5/6 | |||
Touch screen | 4513 | 1 | |||
3 | Drying system | Constant temperature oven | 2 | ,,. The drying system is independent of the printing system. The dry effect can be controlled in accordance with actual condition. The oven temperature can be controlled automatically. | |
Automatic control system | GE-600101 | 2 | |||
4 | Winder machine | Reeling machine | 1 | ,,.. The winder machine adapts friction to reel. The tension is steady and guarantees that the reeling of base fabric is smooth. | |
| Inverter | 2.2kw | 1 | |||
| motor | 2.2kw | ||||
Worm wheel gearbox | 1:10 | 1 | |||
SERVO MOTOR | 4.4kw | 1 |
