Yxnm Serials, 6", Electric Contact Pressure Gauge, Liquid-Filled, Switch Contact, Shock Resistance, All Stainless Steel, Anti-Corrosion, Lower Mount, Manomer

Product Description

Applications Control and regulation of processes Switching of circuits For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments Chemical industry, petrochemical industry, power plants, mining, on-/offshore, environmental technology, machine building and general plant construction Product Features Up to 2 switch contacts per instrument (upper switch and lower switch) Instruments with inductive contacts for use in hazardous areas Working Voltage: 220V Both liquid filled and non-filled are available Both back mount and lower mount (radial) are available Measurement unit could be bar, psi...etc. as per customer request
Specifications

Model	YXNM-100	YXNM-100BF	YXNM-150	YXNM-150BF
Nominal Size	Φ100		Φ150
Connecting Thread	M20×1.5,ZG1/2",G1/2",1/2NPT,G3/8",ZG3/8"
Accuracy Class	±1.6%
Scale Range (MPa)	-0.1~0,-0.1~0.06,-0.1~0.15,-0.1~0.3,-0.1~0.5, -0.1~0.9,-0.1~1.5,-0.1~2.4
	0~0.1,0~0.16,0~0.25,0~0.4,0~0.6,0~1,0~1.6, 0~2.5,0~4,0~6,0~10,0~16,0~25,0~40,0~60,0~100
Upper Limit of Pressure	2/3
Vibration Class	V.H.4
IP Protection Class	IP64. (IP65 must be customized)
Max. Operating Voltage	DC·24V
Max. Power	1W

Company Profile
Wuxi Haitian Special Pressure Gauge Factory (Wuxi Haite Instrument Technology Co., Ltd.) was established in 1996. The factory covers an area of 15 acres and has a total factory area of nearly 20,000 square meters. We specializes in the production of pressure instruments, thermometers and accessories. The company has inherited decades of manufacturing technology and craftsmanship, and has developed numerous intelligent and standardized measurement products.
Professional technology, exquisite craftsmanship, rich experience, and continuous innovation make Haite Instruments highly favored by users. After more than 20 years of hard work, Haitian Instruments has become one of the special instrument production bases with "multiple varieties and complete specifications". The products are widely used in petrochemical, gas, metallurgy, machinery, electricity, medicine, food and aerospace industries.
The YN series of liquid-filled pressure gauges produced by our factory are selected by many domestic major hydraulic engineering hoist hydraulic stations; the YBF series of stainless steel liquid-filled pressure gauges and YM series of diaphragm pressure gauges have been selected by many power plants and petrochemical companies, especially our products matched with the gas turbine unit of the Yuanwang series of aerospace scientific surveying and mapping ships, and its outstanding quality has been widely praised.
We sincerely hope to establish more extensive business contacts with domestic&foreign enterprises, institutions, distributors, and provide customers with high-quality products and fast services as always.
Certifications
Workshop at A Glance
FAQ: Q: Is there minimum order quantity requirment?
A: Basically yes, but it's case by case.
Q: What's the normal delivery time?
A: 10~45 days if no in store
Q: How about the warranty?
A: 1 Year
Q:Is OEM possible?
A: Yes
Q: Is customized product design available?
A: Yes

---
