ISO Standard Forged Stainless Steel/Carbon Steel Water Pipe Flange ASME ANSI B16.5 Welding Neck DIN ANSI Carbon Steel Forged Blind Flange

Product Description

ISO Standard Forged Stainless Steel/Carbon Steel Water Pipe Flange ASME ANSI B16.5 Welding Neck DIN ANSI Carbon Steel Forged Blind FlangeProduct DescriptionFlanges of welding neck, socket welding, threaded, blind, slip on, etc.
Material: Stainless steel 304/304L,316/316L,321,ect. Carbon steel A105/Rst37.2/C22.8/Q235, etc.
Size:1/2"-24"
Pressure:150lbs-2500lbs PN0.6-PN16.0
Facing:RF/RJ/ FF/MF/TG/
Standard:BS4504/GOST/ANSI(ASME)16.5 16.47/DIN/JIS/UNI/GB...
Slip On Weld Flange/Flat Welded Flange with Neck
Slip on weld fange can be slid onto a pipe and then welded in place.It is made of carbon steel,alloy steel,and stainless steel.The industrial processes come into die forging,and machining,We can provide a wide range of slip-on weld flanges,following on standards like GOST33259,GOST12821/GOST12820,BS4504, ASME B16.5,ASME B16.47,DIN 2634,DIN 2636,JIS,UNI,...and so on.
SIze of slip on weld flange
Slip on weld flange: 3/8"~40"
DN10~DN1000
Pressure
American Series: CLASS 150, CLASS 300, CLASS 400, CLASS 600, CLASS 900, CLASS 1500, CLASS 2500
European Series: PN 2.5, PN 6, PN 10, PN 16, PN 25, PN 40, PN 63, PN 100, PN 160, PN 250, PN 320, PN 400
Flange Facing Types
American Series:Flat Face (FF), Groove (G), Ring Joints Face(R)Butt welding flange/Weld Neck Flange/WN Flange
It refers to a flange with a neck and a round pipe transition and butt welding connection with the pipe. We produce ASME B16.5 butt welding flanges, GOST12820, GOST12821, GOST33259, BS4504,ASME B16.47 butt welding flanges, DIN 2631 butt welding flanges Welding flanges, DIN 2637 butt welding flanges, DIN 2632 butt welding flanges, DIN 2638 butt welding flanges, DIN 2633 butt welding flanges, etc. Welding flanges are suitable for pipelines with large fluctuations in pressure or temperature or high temperature, High pressure and low temperature pipelines are also used for pipelines that transport expensive, flammable and explosive media. Butt welding flanges are not easily deformed, have good sealing, and are widely used.
Size
Butt welding flange: 3/8"~160"
DN10~DN4000
pressure
American series: CLASS 150, CLASS 300, CLASS 400, CLASS 600, CLASS 900, CLASS 1500, CLASS 2500
European series: PN 2.5, PN 6, PN 10, PN 16, PN 25, PN 40, PN 63, PN 100, PN 160, PN 250, PN 320, PN 400
Flange sealing surface type
American series: flat surface (FF), raised surface (RF), grooved surface ( G), Concave and convex surface (MFM), Ring connection surface (RJ)Blind Flange
Blind flanges are made of carbon steel,stainless steel and alloy steel,etc.They are used to seal or block off a pipe, like a cover or cap. We can provide a wide range of blind flanges,in accordance to standards like GOST33259,GOST12821/GOST12820,BS4504, ASME B16.5,ASME B16.47,DIN 2634,DIN 2636,and so on.
Size
Blind Flange: 3/8"~100"
DN10~DN2500
Pressure
American Series: CLASS 150, CLASS 300, CLASS 400, CLASS 600, CLASS 900, CLASS 1500, CLASS 2500
European Series: PN 2.5, PN 6, PN 10, PN 16, PN 25, PN 40, PN 63, PN 100, PN 160, PN 250, PN 320, PN 400
Flange Facing Types
American Series:Flat Face (FF), Raised Face (RF), Groove (G), Female(F), Ring Joints Face(RJ) Flat Welded Flange/Plate Flange
These flat welding flanges are GOST33259,GOST12820,GOST12821,BS4504, ASME B16.5 flat welding flange, ASME B16.47 flat welding flange, DIN 2634 flat welding flange, DIN 2635 flat welding flange, DIN 2630 flat welding flange, DIN 2636 flat welding method Flanges, DIN 2631 flat welding flanges, DIN 2637 flat welding flanges, etc. Flanges are parts that connect pipes to each other and are connected to pipe ends. There are holes on the flange, and bolts make the two flanges tightly connected. Gaskets are used to seal between flanges. Flat welding flanges are suitable for steel pipe connections with a nominal pressure not exceeding 2.5MPa. The sealing surfaces of flat welding flanges can be made of smooth, concave-convex and tongue-and-groove types.
Size
Flat welding flange: 3/8"~40"
DN10~DN1000
Pressure
American series: CLASS 150, CLASS 300, CLASS 400, CLASS 600, CLASS 900, CLASS 1500, CLASS 2500
European series: PN 2.5, PN 6, PN 10, PN 16, PN 25, PN 40, PN 63, PN 100, PN 160, PN 250, PN 320, PN 400HEBEI CANGRUN PIPELINE EQUIPMENT CO.,LTD.is a professional flange manufacturer and supplier,based in China. we have been manufacturing all types of flanges and pipe fittings,strictly according to ISO9001 quality management system,thus having reliable quality and reasonable price,Also, we offer free samples and a three-year quality warranty,and OEM service is available upon request. We have been engaged in the production of industrial flanges for nearly 20 years. We know how to make a product with an international advanced level. If you are in need of industrial flanges and pipe fittings,please do not hesitate to contact us at HEBEI CANGRUN PIPELINE EQUIPMENT CO.,LTD .We look forward to working with youProductionProduction process : raw material--cutting--heating--forging--heat treatment--maching--inspection.-washing-ex-working. Quality ControlWe have strict quality control system.
Our quality control department will test from the material to production line, packing line, shipping line.
So Please rest assured that the quality will be good and stable.
Packaging & ShippingPackaging:
1. Plywood pallet
2. Plywood case
3. According to customer's requirements
Shipping:
We could ship by sea, by air, and for small goods we could ship by express
Certifications
Company ProfileHEBEI CANGRUN PIPELINE EQUIPMENT CO., LTD.
Our company has strong technical force. With complete production equipment, it has more than 120 sets of production equipment, including 8000 tons of four column press, 1600 tons of pushing machine, 800 tons of large pipe bending machine and 8 tons of forging hammer. It can produce valves, flanges, elbows, elbows, tees, crosses, reducers, pipe caps, sockets and other pipe fittings and extension products of all specifications of carbon steel, alloy steel, stainless steel, pipeline steel, low-temperature steel and other materials according to domestic and international and industrial standards, We adhere to quality first, customer first, is our purpose.
FAQ1. What about your MOQ ?
MOQ is one piece, we can offer sample for free, customer just pay the transport charge.2.What is the average lead time?For samples, the lead time is about 7 days.
For mass production, the lead time is 20-30 days after receiving the deposit payment.
The lead times become effective when (1) we have received your deposit, and (2) we have your final approval for your products. If our lead times do not work with your deadline, please go over your requirements with your sale. In all cases we will try to accommodate your needs. In most cases we are able to do so.3.What about payment term ?You can make the payment to our bank account, Western Union or PayPal:30% deposit in advance, 70% balance against the copy of B/L
Contact Us
If any questions feel free to contact us directly.
Welcome to contact us if any inquiry. Hope to start long-term good business.

---
