US$17,500.00-18,500.00
|
1 Piece
(MOQ)
|
Basic Info.
Spindle Number
Single-Spindle
Control System
Syntec Controller
Table
Vacuum Adsorption Table
Guide Rail
Taiwan Hiwin Square Guide Rail
Transmission
Helical Rack
Spindle Power
Water Cooling Spindle
Lathe Bed
T-Shape Heavy Duty Bed Structure
Application
Wooden Industry
Transport Package
Plywood Package
Specification
1300*2500*200mm
Product Description
Advantages of 5 axis cnc milling machine:
♦ Thickened and strengthened heavy steel structure, which is reliable and durable, with long working life. It can make the machine run smoothly and accurately.
♦ Diversified control processing speed can control the working speed, traveling speed and dropping tool speed, and it improves the quality and efficiency greatly.
♦ Easy and safe operation and low maintenance cost. To make you learn quickly how to operate safely the machine,
free training in our factory will be offered. Less time and less money will be cost on the maintance because of the top quality of the machines.
♦ Many optional configuration and OEM service available. According to your requirement, different configurations will be offered. OEM service is available for you.
Technicial data of 5 AXIS CNC router machine
Maximum working size
| X Axis:1300mm/1200mm |
| Y Axis : 2500mm/2400mm | |
| Z Axis: 600mm | |
| A Axis: ±110° | |
| C Axis: ±360° | |
| Table structure | Cast Steel Structure |
| X,Y axis transmission | Germany Rexroth linear Guide rails H30, Germany WMH rack |
| Z axis transmission | Germany Rexroth linear Guide rails H30, TAIWAN PMI ball screw |
| Spindle | 12kw, Italy Hiteco / HSD spindle, air-cooled |
| Tool Magazine | Disc-type ATC (with 8 tools) |
| Tool holder | HSk63F |
| Spindle Speed | 6000-24000r/min, variable speed |
| Working Voltage | AC220V/60Hz 1-phase or AC380V 60HZ 3-phase |
| Motor and driver | YASKAWA |
| Inverter | Delta inverter |
| Command | G code |
| Controller | Taiwan Syntec controller |
| Software | UG software |
| Pump | Oil free vacuum pump |
