14" X24" Variable Speed Woodturning Lathe with Delta Inverter (MC1424VS)

Product Description

Specifications:

01) Description: 14"x24" wood lathe with Rotatable headstock

02) Motor(Input W): 750W (with 750W inverter)

03) No. of Speed: Variable

04) Spindle Speed: 0~1200rpm Low Speed, 0~3200rpm High Speed

05) Swing Over Bed: 368mm(14.5")

06) Distance Between Centers: 24.5" (620mm) or 47" (1200mm) with optional extension bed

07) Drive Spindle: M33X3.5 or 1"8RH thread

08) Headstock and Tailstock Taper:MT2#

09) Face Plate: 152mm(6")

10) Tool Rest: 200mm(8")

11) Packing Size(mm): 1125X580X515

12) NW/GW: 137/165KGS

13) Units per 20-foot container:80 pcs

Main features:
* Electronic Inverter Variable Speed Lathe with 750W TAIWAN DELTA brand Inverter
* Two belt ratios for high torque when turning large diameters
* Digital speed display on headstock
* Quick belt change construction headstock
* All cast iron constuction for high stability and vibration free running
* Cast iron stand with provision for a shelf
* Headstock rotates for outboard turning
* 36 Indexing Positions Function
* With Forward/Reverse running function
* Magnetic control box can be positioned where required
01) Description: 14"x24" wood lathe with Rotatable headstock
02) Motor(Input W): 750W (with 750W inverter)
03) No. of Speed: Variable
04) Spindle Speed: 0~1200rpm Low Speed, 0~3200rpm High Speed
05) Swing Over Bed: 368mm(14.5")
06) Distance Between Centers: 24.5" (620mm) or 47" (1200mm) with optional extension bed
07) Drive Spindle: M33X3.5 or 1"8RH thread
08) Headstock and Tailstock Taper:MT2#
09) Face Plate: 152mm(6")
10) Tool Rest: 200mm(8")
11) Packing Size(mm): 1125X580X515
12) NW/GW: 137/165KGS
13) Units per 20-foot container:80 pcs
Optional Accessories:
* With extra extension bed MC1624-EX+OTR available as optional accessory, which could extend the total working lenght to 1200mm(47") or Extend the bowl turning capacity to 720mm(28")
MC1424VS+MC1624-EX+OTR

---
