SE-2300V Intelligence Efficiency Precision Energy-saving Eco-friendly All Electric Injection Molding Machine

Product Description

All Electric Injection Molding Machine

Performance characteristic:
Zero-resistance clamping injection guider structure, heavy loaded guider device supported by linear track, better wear resistance, lower friction and more smooth operation. Optimize mold structure, tie bar no touch with moving platen,no lubrication. The system has high rigidity and strength, guarantee the accuracy of platen parallel excellently.
T-slot & screw fixation platen embedded moldlocating ring design, high-standard clampling system reduces mold loss and makes more easy mold installation.
Fast and smooth mold movement, high torque, less resistance. Clamping servo motorconnects ball screw, flexible operation and simply maintenance. High- quailty belt, warranty 10 years;superior rotating wheel,low inertia.
Top responsibility servo motor and high toreque ball screw is key element, origin Japan technology to keep advantage leading ir the word, precise for mold movement.
Parameter:

MODEL			SE-2300V
CLAMP TONNAGE		kN	2300
SPACE BETWEEN Tl E-BARS		mm	625x575
PLATEN DIMENSION		mm	880x860
OPEN STROKE		mm	550
MOULD THICKNESS		mm	250-680
EJECTOR STROKE		mm	150
EJECTOR FORCE		kN	49
EJECTOR NUMBER			13
MACHINEWEIGHT		T	11
SCREW DIAMETER		mm	40	45	50	45	50	55	50	55	60
INJECTION CAPACITY		cm3	232	294	363	366	452	546	511	618	735
INJECTION WEIGHT (PS]		g	212	268	331	333	411	497	465	562	669
PLASTICIZING CAPACITY (PS)		kg/h	91	123	150	123	150	175	136	212	242
SCREW SPEED		rpm	350			350			320
HEATER BAND			3+1			4+1			4+1
HE/JER POWER		kW	12.3			14.4			17.5
NOZZLE PRESSING FORCE		kN	29.4			29.4			39.2
STANDARD			570			790			1020
INJECTION SPEED		mm / s	200			200			160
INJETION RATE (PS)		cm3 /s	252	318	393	318	393	475	314	380	452
INJECTION PRESSURE		Mpa	265	210	170	247	200	165	218	180	152
		kgf/cm2	2700	2135	1730	2519	2040	1686	2135	1836	1560
MAX.INJECTION HOLD PRESSURE		Mpa	213	168	136	197	160	132	175	144	121
		kgf/cm2	2169	1714	1388	2015	1632	1349	1707	1470	1186
TOTAL POWER		kW	42.3			68.4			59.6
OPTION			570H			790H			1020H
INJECTION SPEED		mm / s	350			350			250
INJETION RATE (PS)		cm3 /s	441	557	688	557	688	831	500	602	718
INJECTION PRESSURE		Mpa	265	210	170	247	200	165	218	180	152
		kgf/cm2	2700	2135	1730	2519	2040	1686	2135	1836	1560
MAX.INJECTION HOLD PRESSURE		Mpa	213	168	136	197	160	132	175	144	121
		kgf/cm2	2169	1714	1388	2015	1632	1349	1707	1470	1186
TOTAL POWER		kW	66.3			86.3			89.5
We reserve the right to change specifications without prior notice.

OVERALL DIMENSIONS
PLATEN DIMENSIONS
Application:
The SE series of all-electric injection molding machine are more suitable for household appliance, medical,electronic optics, packaging,auto parts, and other industries with its advantages of high speed, high efficiency, high precision, energy saving and environment cleaning .

Related products:
After Sales Service
Debugging before shipping: Before shipping,all the lines will be strictly tested to ensure that customers use smoothly.
Installation at site: strict supervision for installation,commissioning and running.
Customers files establishment: detailed record on customers equipment information,and the replacement of spare parts are kept in profile for a long term save.
Regular visit system:after equipment installation and running,call to customers within one week,life-long follow-up service to the quality of products and services,to ensure that customers are worry-free.
Trouble shoot response time:establish professional sfter-sale service team,after breakdown happened,ensure engineers to provide solution within 24 hours,and solve the problem
Spare parts:Sufficiently supply,delivery in time
