Product Details
Product Description
Product Description
Brand: YOKOGAWA
Type:AIP830-111
Origin: Japan
Warranty: 365 days
Colour: new/used
Rugged construction for industrial applications Splash proof, protection class IP 55 Frequency range from 4 Hz to 1000 Hz Part of the A6000 and MMS 3000 system for rotating machinery Radioactive radiation resistantMeasuring principle Low tuned system for absolute vibration measurement Mechanical / electrical conversion Electro-dynamic Operation direction PR 9268/20x-… vertical PR 9268/30x-… horizontal Signal frequency and amplitude Frequency range 4 Hz to 1000Hz Vibration amplitude ±1500µm Sensitivity Sensitivity at 80 Hz 20°C (68°F) and 100 kΩ load 29 mV/mm s-1 Tolerance ±5% Linearity error<2% Transversal sensitivity PR 9268/20x-… 0.13g PR 9268/30x-… 0.27g Damping factor D approx. 0.56 at 20°C /68°F approx. 0.42 at 100°C/ 212°F Effective capacities <1.2 nF inclusive cable Electrical data of meas. coil DC resistance 375 Ohm For Channel Clear detection, A6120 requires additional serial resistance of approx. 1500 Ohm within sensor circuit.
This reduces the sensitivity to 28.5 mV/mm s-1. Inductance <90mH Permissible acceleration Measuring direction 10g continuously 20g short time Transversal direction 2g Temperature range Sensor without connector Continuous -10 to +80°C (14 to 176°F) Short time (1 minute) -10 to +105°C (14 to 221°F) Storage / transport -10 to 70°C (14 to 158°F) Environmental conditions Protection class IP55 Relative humidity 0 to 100% (non-condensing)Electro-dynamic absolute vibration sensor, horizontal measuring direction with a connection cable of 3 m, protection hose and open cable end 9210-06000n PR 9268/201-100-RAD Electro-dynamic absolute vibration sensor, vertical measuring direction with a connection cable of 5 m, protection hose and open cable end 9210-06001n PR 9268/202-100-RAD Electro-dynamic absolute vibration sensor, vertical measuring direction with a connection cable of 8 m, protection hose and open cable end 9210-06002n PR 9268/200-100-RAD Electro-dynamic absolute vibration sensor, vertical measuring direction with a connection cable of 3 m, protection hose and open cable end 9210-06003n PR 9268/302-100-RAD Electro-dynamic absolute vibration sensor, horizontal measuring direction with a connection cable of 8 m, protection hose and open cable end
>>
