15kg/H Commercial Refrigerant Dehumidifier Commercial Central Air Conditioner

Product Description

1)The Feature of 15kg/h commercial refrigerant dehumidifier
1.Headpower company has rich experience in design and manufacturing of refrigeration dehumidifiers.Its series of refrigeration dehumidification equipment for air dehumidification are applicable for places with need of dehumification, such as national defense engineerings,civil air defense engineerings,tabacco and petrochemical industries,metrostations,aerospace,decontamination engineerings,lab,telecommunication equipment rooms,archives rooms, foor rooms,pharmaceutical and film workshops,and specialty glass manufacturing.
2.Headpower dehumidifiers include series of regular dehumidifiers,pipe dehumidifiers,heating pipe dehumidifiers, dehumidifiers forcoastal engineerings,dehumidifiers for tabacco storehouses, dehumidifiers for air-conditioning of undergroud engineerings,full fresh air dehumidifiers,and united dehumidifiers
2)Product model:

items type			CFT8	CFT10	CFT16	CFT20	CFT25	CFT32	CFT40	CFT50	CFT60	CFT80	CFT100
dehumidity capacity		kg/h	8	10	16	20	25	32	40	50	60	80	100
cooling capacity		KW	14	16.6	28	33	42	56	66	83	99	132	165
power supply			220V/1PH-50HZ 380V/ 3PH-50HZ		380V/3PH-50HZ
protection devices			high &low pressure switch,over load protector,phase order protection,internal over-heat protector ,frequent boot protector
operation and control			microcomputer control automatically,failure warning,trouble self-checking, operation balance,Timer on/off
compressor	type		hermetic scroll compressor
	power	KW	3.75	4.5	3.75×2	4.5×2	3.75×3	3.75×4	4.5×4	4.5×5	9×3	9×4	9×5
heat exchanger of air side	exchanger type		copper tubes with aluminum fin
	fan type		ultra-low-noise centrifugal
	air flow	m3/h	2600	3200	5200	6400	7800	10800	12800	16000	19200	25600	32000
	external static pressure	Pa	0/100	0/120	0/150	0/180	200	220	250	280	350	350	400
	motor power	KW	0.55	0.75	0.55×2	0.75×2	2.2	3	4	5.5	7.5	11	15
heat exchanger of outdoor side	exchanger type		hydrophilic film aluminum fins with copper tubes
	fan type		low-noise axial
	air flow	m3/h	5000	6000	11000	13000	17000	22000	25000	33000	39000	54000	66000
	motor power	KW	0.25	0.28	0.25×2	0.28×2	0.55×2	1.1×2	1.1×2	0.75×3	1.1×3	1.1×4	1.1×5
refrigerant/volume control			R22/ thermostatic expansion valve
operation noise		dB(A)	56	59	62	63	65	66	66	68	70	71	72
weight		kg	220	240	320	380	450	520	600	680	810	980	1160
dimensions (L×W×H)	indoor unit	mm	1050×600×1650	1100×600×1700	1450×650×1700	1600×800×1800	1800×800×1800	2000×850×1980	2100×900×2050	2100×1160×2200	2200×1200×2200	2400×1380×2200	2500×1600×2400
	outdoor unit	mm	840×840 ×950	840×840 ×950	1050×1050×1300	1050×1350×1300	1200×1350×1300	2250×1050×1150	2300×1100×1250	2300×1100×1500	2300×1200×1400	2300×2100×2000	2300×3100×2000
Note: 1. The above parameters are measured under the following conditions: indoor air temperatureDB27 ºC,WB21.2ºC; For air cooled type, outdoor air temperature DB35ºC,WB24ºC; For water cooled type, the inlet/outlet water temperature is 30ºC/35ºC. 2. The specifications are subject to change without notice for improvement. 3. Any special requirements please notify us in advance.

3) Dispaly:
4)Packing and shipping
5)Our company file

---
