Fiber Grade Waste Baled Pet Bottle Brick Plastic Hot Washing Recycling Machine/Equipment/Plant

Product Description

Product Description
HAORUI 4000kg/h Fiber Grade Waste Baled Pet Bottle Brick Plastic Hot Washing Recycling Machine/Equipment/Plant
This 4000kg/h PET bottle hot washing recycling machine was we shipped to Nigeria already.
Ths customer is our cold customer, mainly produce food or fiber grade PET flakes, and export to Europe and Turkey.
He bought our 3tons/h line in 2019, and now he has good business ,and expand his factory , bought a 4tons/h line .
our Advantage
1. Long manufacturing history over 30years.
Our factory was established in 1992. Over 30 years experience,we can give customers a professional solution, help customer avoid investment mistake and reduce learning cost.
2.R&D engineer 5 persons
Based on our excellent R&D engineers,we keep improving our machines, insure our machines newest technology ,and machines excellent performance with customers.
3.We always keep the principle "quality is first".
We promise to use all new technology,new material ,enough thickness to keep the good quality, grantee is 1 year.
4.100+ Workers and 30000m2 factory
We are 100% end manufacturer, all machines from first metal cut to final painting , all process are finished in our own factory ,so we can provide most competitive price and short delivery time.
Small capacity line within 25days, big capacity line within 50days.
5.13 patent certifications
We keep improving our technology, we have our own PET bottle recycling factory in China and use our machines,So we know what problem the machines have during working and keep improving it and get 13 patent certifications,We do good business in China and created famous "HAORUI"brand.
6.OEM and Export
OEM or Agent is welcomed.And over 40 sets of PET bottle washing line(four 6000kg/h capacity in Nigeria ,Ghana etc), PP PE HDPE LDPE washing line ,pelletizing machine were installed in Middle East,Africa,South America,South East, South Asia ,USA and so on, created Famous "HAORUI" brand in Africa.

Detailed Photos
Bottle pre-washing system&Trommel screen
Specially designed for big capacity line,it is to remove the impurities before crushing,like the sand ,stone,and even mud on the bottles, that is a very important process to clean the plastic , reduce the production cost and reduce damaging to the following machines.

Lable remover Unique design blade quantity and shape,with patent certification.
Our most hot-selling item High label remove rate(round bottle> 99% , bale bottle> 96% )
Don't damage bottles, reduce neck broken, reduce material loss. Good design label separation chamber, can used for wet bottle, label come out well, not block.
Crusher
110kw motor power
16pcs rotating blades, 4pcs fixed baldes Heavy duty model, high speed crushing

Floating tank
Thick metal,more than 4mm thickness
Separate caps and rings
Flakes come out smooth, don't block.
Hot washer
Full wash the dirty, glue, oil...
Key point to make the flakes clean and bright, sell a higher price and make better more new products. Plate thickness 4mm at least, or customized according to customer.
Double layers with thick insulation cotton, low energy consumption
Over designed size, insure really capacity,insure all flakes stay in hot water 15-20minutes to reach full washing.
With time controller ,easily operate.

High speed friction washer
Remove the dirty sand of the flakes through high speed friction,thus PET flakes will be very clean.

Dewatering machine
Blade thickness 6mm-12mm (carbon steel or SS304),customized according to customer
Blade material after heat treating, longer using time
Blade is detachable, saving accessories cost
Easily change mesh and blade.Saving maintenance time.
The part of the inlet and outlet using thick metal,machine long lifetime.
Zig zag label separator
Unque design, with 3sets blowers to separate the label,means 3 times separation. the separation rate is much higher.


Our Customers
6tons/h line in Nigeria 3tons/h line in Ghana
3tons/h line in Nigeria 3tons/h line in Kenay
Product Parameters

SN:	Item name:	Function
1	Bale Opener machine	Feeding the material equally
2	Conveyor	Feeding material
3	Trommel and bottle prewashing system	Remove the sand, rocks and other dirty from the bottles
4	Conveyor	Feeding material
5	Label Remover	Remove labels from Bottles
6	Manual sorting table	Sorting out remain labels, remain different bottles and so on
7	Crusher	Crushing the bottles into flakes
8	Screw Conveyor	Conveying material
9	1st Auto floating washing tank	Washing out the Floating caps, rings and dirty
10	1st High Speed Friction washer	With high speed Friction Washing out dirty
11	Hot washing tank	With Hot water washing and chemical to remove glue, oil, and dirty
12	Screw Conveyor	Conveying material
13	2nd High Speed Friction washer	With high speed Friction Washing out dirty and Chemical water from flakes
14	2nd Auto floating washing tank	Washing out chemicals, floating caps, rings and dirty,
15	3rd Auto floating washing tank	Washing out floating caps, rings and dirty,
16	Horizontal Dewatering Machine	Remove the humidity from the flakes
17	Hot Air Drying system	Drying the flakes
18	Zig-Zag Air Classifier	Remove the fin dust and small labels
19	Flakes color sorter machine
20	Flakes polymer sorter machine
21	Automatic packing system	Collecting the flakes
22	Electrial contol panel	Used to control the whole Line
23	Free spare parts
PET bottle washing/recycling line/plant can be customized according to your requests.

machine	PET bottle crushing washing drying line
capacity	4000kg/h
Solution	Dirty PET bottle into clean and dry PET flakes
Flakes size	8-16mm
Flakes grade	Food /fibre
Machine size	100m(L)*6m(W)*6m(H)
Energy consumption	500kw/h
Water consumption	6tons/h(recycled)
workers	15~20 workers

Final flakes

---
