| SPECIFICATION |
| AC Power supply | Phase 1 +N +PE |
| Rated Power | 9.6KW |
| Rated Voltage | AC 240V, 50/60HZ |
| Rated Current | 48A |
| Charge Mode | Type 1 SAE J1772 |
| Plugs | Cable Length: 25 Feets , Mode 3 |
| Charging Control | Smart phone APP control, Tap card control, Plug and charge |
| Display Screen | 3.8 inch LCD screen |
| Indicator Light | 4 LED lights |
| Communication Interface | WIFI, BLUETOOTH, 4G, LAN |
| Communication Protocol | OCPP 1.6J |
| Safety Protection | Over current protection, over voltage protection, under voltage protection, over temperature protection, leakage protection, Unconnected PE ground protection, etc. |
| RCD | Type A (AC 30mA) + DC6mA |
| Relative humidity | 95%RH, No water droplet condensation |
| Vibration | 0.5G, No acute vibration and impaction |
| Installation Location | Indoor or outdoor, good ventilation, no flammable, explosive gases |
| Mounting | Wall- mounted or Pole-mounted ( mounting pole is optional) |
| Altitude | 2000m | IP Code | IP55 |
| Storage temperature | -40 ~ 75℃ | Operation temperature | -30 ~ 50℃ |
| Product Weight: | 4.0KG | Carton Dimension (H*W*D) | 455mm | 260mm | 230mm |
| Certification | ETL, FCC |
