| US$160.00-190.00 | 1 Piece (MOQ) |
| Specifications | ||
Camera | Image Sensor | 1/2.8" Progressive Scan CMOS |
| Minimum Illumination | Color:0.001 Lux @ (F1.5,AGC ON); B/W:0.0005Lux @ (F1.5,AGC ON) | |
| Shutter | 1/25s to 1/100,000s;Supports delayed shutter | |
| Aperture | DC drive | |
| Day/Night Switch | ICR cut filter | |
| Digital zoom | 16x | |
Lens | Focal Length | 4.7-155mm,33x Optical Zoom |
| Aperture Range | F1.5-F4.0 | |
| Horizontal Field of View | 60.5-2.3°(wide-tele) | |
| Min Working Distance | 100mm-1500mm (wide-tele) | |
| Zoom Speed | Approximately 3.5s (optical, wide-tele) | |
Compression Standard | Video Compression | H.265 / H.264 / MJPEG |
| H.265 Type | Main Profile | |
| H.264 Type | BaseLine Profile / Main Profile / High Profile | |
| Video Bitrate | 32 Kbps~16Mbps | |
| Audio Compression | G.711a/G.711u/G.722.1/G.726/MP2L2/AAC/PCM | |
| Audio Bitrate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) | |
Image (Maximum Resolution:1920*1080) | Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps(1920 × 1080, 1280 × 960, 1280 × 720) |
| Third Stream | 50Hz: 25fps (704 x 576); 60Hz: 30fps (704 x 576) | |
| Image Settings | Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browse | |
| BLC | Support | |
| Exposure Mode | AE / Aperture Priority / Shutter Priority / Manual Exposure | |
| Focus Mode | Auto Focus / One Focus / Manual Focus / Semi-Auto Focus | |
| Area Exposure / Focus | Support | |
| Defog | Support | |
| Image Stabilization | Support | |
| Day/Night Switch | Automatic, manual, timing, alarm trigger | |
| 3D Noise Reduction | Support | |
| Picture Overlay Switch | Support BMP 24-bit image overlay, customizable area | |
| Region of Interest | Support three streams and four fixed areas | |
Network | Storage Function | Support Micro SD / SDHC / SDXC card (256G) offline local storage, NAS (NFS, SMB / CIFS support) |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 | |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G) | |
Smart Features | Smart Detection | Cross-border detection, area intrusion detection, entering / leaving area detection, hovering detection, personnel gathering detection, fast motion detection, parking detection / take detection, scene change detection, audio detection, virtual focus detection, face detection |
Interface | External Interface | 36pin FFC (Network port, RS485, RS232, CVBS, SDHC, Alarm In/Out Line In/Out, power) |
General | Working Temperature | -30ºC~60ºC, humidity≤95%(non-condensing) |
| Power supply | DC12V±25% | |
| Power consumption | 2.5W MAX(IR, 4.5W MAX) | |
| Dimensions | 97.5x61.5x50mm | |
| Weight | 268g | |
