| Description | IPV6 Cat 4 openWRT 4g lte cpe router |
| Item no. | HYZR8300 |
| Application Scenarios | Home，Office，IoT，Security |
| Concurrent Clients | 25 |
| CPU | MTK7628KN |
| Interface | 1*FE Mbps WAN，2*FE Mbps LAN |
| Button | Reset，WPS，Power |
| Power Suppply | DC 12V/1A |
| Flash/Memory | 2MB/8MB |
| SIM Card | 2 FF |
| LED | PWR，WiFi，Internet，Interface，Signal Strength LED |
| Dimensions | 180*130*32mm |
| Antennas | 2.4G:2T2R 4G:2T2R |
| Antenna Gain | 5dBi |
| Frequency | 802.11b/g/n：2.4~2.4835GHz |
| Radio Rate | 2.4G: Up to 300Mbps |
| WPS | Support |
| Wireless Security | WPA-PSK/WPA2-PSK、WPA/WPA2 |
| Modulation | 11b：CCK，QPSK，BPSK 11g：OFDM 11n：QPSK，BPSK，16-QAM，64-QAM |
| Receiver Sensitivity | 2.4G: 11b: <-84dbm@11Mbps； 11g: <-69dbm@ 54Mbps； 11n: HT20<-67dbm HT40: <-64dbm |
| 4G Module | LTE CAT4 |
| GNSS | GPS, GLONASS, BeiDou/Compass, Galileo, QZSS |
| WiFi Setting | Wireless Setting、Channel bandwidth Setting、WPS |
| Status | CPU Status、Interface Status、4G Status Client List Internet Status |
| Network | LAN WAN DHCP APN |
| Traffic assistant | Statistics and display the usage of traffic in 4G mode |
| Sys | Username Managerment Reboot Upgrade/Restore/Bankup Sys time & date Sys logs |
| Setting Guide | Type of connect Internet Network WiFi |
| Frequency | FDD: B1/B3/B5/B8; TDD: B38/B39/B40/B41; WCDMA: B1/B8; GSM: B1/B8; |
| FDD: B1/B3/B7/B8/B20/B28A; WCDMA: B1/B8; GSM: B3/B8; | |
| FDD: B2/B4/B5/B12/B13/B14/B66/B71; WCDMA: B2/B4/B5; | |
| FDD: B1/B2/B3/B4/B5/B7/B8/B28; TDD: B40; WCDMA: B1/B2/B5/B8; GSM: B2/B3/B5/B8; | |
| FDD: B2/B4/B12; WCDMA: B2/B4/B5; | |
| FDD: B1/B3/B5/B7/B28; WCDMA: B1/B5; | |
| FDD: B3/B7/B28; | |
| FDD: B1/B3/B5/B7/B8/B20; TDD: B38/B40/B41;WCDMA: B1/B5/B8;GSM: B3/B8; | |
| FDD: B1/B3/B8/B18/B19/B26; TDD: B41; WCDMA: B1/B6/B8/B19; | |
| FDD: B4/B13; | |
| Operating Environment | Operating Temperature:Normal:0°C to +45°C; Operating Temperature:-20° C to +70° C Operating Humidity:5%~ 95% Storage Humidity:5%~ 95% |
| Dimension | Device: 180/130/32mm; |
| Pack Box: 281/278/51mm; | |
| Package | Device*1, Adapter*1, User manual*1, Antenna*4pc, Ethernet cable*1pc; |
