| Model | PME-CM510CF | PME-CM510CC | PME-CM510AD | PME-CM510LT |
| Motor | CHANGFA | CHANGCHAI | CHANGCHAI | WITHOUT ENGINE |
| Engine type | single cylinder,horizontal,evaporating water-cooled,4-stroke | single cylinder,horizontal,evaporating water-cooled,4-stroke | forced air-cooled,direct injection,vertical | |
| Type of Injection | direct | direct | direct | |
| Bore(mm) | 100 | 100 | 92 | |
| Stroke(mm) | 115 | 115 | 75 | |
| Rated Power(kw/hp) | @2200 12.1/16 | @2200 12.1/16 | @3600 12.1/16 | |
| Compression ratio | 17.5:1 | 17.5:1 | 19:1 | |
| capacity of water tank(L) | 12 | 12 | ||
| Capacity of fuel tank(L) | 12 | 12 | | |
| Starting System | Electric Starting | Electric Starting | Electric Starting | |
| MIXER SPECS | ||||
| Drum Volume(L) | 510 | 510 | 510 | 510 |
| Mixing Capacity (L) | 350 | 350 | 350 | 350 |
| Concrete output (m3/h) | 20 | 20 | 20 | 20 |
| Winch/Elevator | + | + | + | + |
| Lifting Height(m) | 25 | 25 | 25 | 25 |
| Whell size | 205/75/R14 | 205/75/R14 | 205/75/R14 | 205/75/R14 |
| N.W./G.W. [kg] | 1650 | 1650 | 1550 | 1500 |
| Package size (L x W x H) [cm] | 230*135*275 | 230*135*275 | 230*135*275 | 230*135*27 |
