Themax Conveyor Belt Vulcanizing Press Machine

Product Description

Product Description We can design various kinds of non-standard plate vulcanizing pressures according to you requirements.
Technical Parameters:
1.Machine Maximum size: from 650MM-4200MM;
2.Voltage: 380V 660V 480V 440V 415V 400V or 220V;
3.Fast Cooling time: 5 minutes (from 145 degrees down to 70 degrees or less);
4. Time for temperature raise (from normal temperature to vulcanizing temperature) no more than 50 minutes;
5.Vulcanizing pressure:1.8MPa (details refer to users' specifications and factory markings);
6.Time of heat preservation for vulcanizing could be adjusted according to thickness of the rubber belts;
7. Splicing length of rubber conveyor belt for vulcanizing jointing could be connected together by single or several pieces if
necessary;
8. Make clear for model and specification of product and indicate width and tensile strength of rubber conveyor belt as well as tension in kilogram required for vulcanizing jointing when ordering products.
9. Users could order spare electric pumps additionally according to requirements.
Specification

Model	Belt width(mm)	Power(kw)	Dimensions	Weight(kg)	Single most important
			(L*W*H mm)
ZLJ-650*830	650	9.5	1370*830*630	430	45
ZLJ-650*1000		10.8	1370*1000*630	500	66
ZLJ-800*830	800	11.2	1520*830*630	535	70
ZLJ-800*1000		13.5	1520*1000*630	575	79
ZLJ-1000*830	1000	14.1	1720*830*630	595	82
ZLJ-1000*1000		15.7	1720*1000*630	620	95
ZLJ-1200*830	1200	16.5	1920*830*710	800	96
ZLJ-1200*1000		17.2	1920*1000*710	870	113
ZLJ-1400*830	1400	18.6	1930*830*760	930	107
ZLJ-1400*1000		20.7	2120*1000*760	1180	132
ZLJ-1600*830	1600	21.5	2320*830*800	1270	120
ZLJ-1600*1000		22.3	2320*1000*800	1460	146
ZLJ-1800*830	1800	23.3	2520*830*850	1380	137
ZLJ-1800*1000		25.6	2520*1000*850	1650	164
ZLJ-2000*830	2000	27.2	2720*830*950	1760	154
ZLJ-2000*1000		30	2720*1000*950	1860	182
ZLJ-2200*830	2200	29.2	2920*830*950	1860	165
ZLJ-2200*1000		34.1	2920*1000*950	1970	198

Packaging & Delivery
Packaging Details
Equipment painting completed before delivery, and then wrapped with stretch film, avoid rubbing the paint off the surface, wooden packaging can be customized
Our Service
* Our engineers can design target machines for customers and send them the drawing to confirm.
* We supply overseas engineer service and help to train your workers to operate the machine.
* We are always on the side of saving your cost.
* In the process of production, we will take photos and send to customers for their track the progress.
FAQ
1. Q: Are you a manufacturer or trade company?
A: We are the manufacturer. We have our own plant,worker and techniques research developing department.
2 .Q: Where is your factory located? How can I visit there?
A: Our factory address is located in the beautiful Qingdao West Coast Economic Zone Nearest airport is Qingdao liuting international airport kindly send plane information in advance, so that we can pick you up at the airport, and book hotels as you require.
3. Q: What are your hot sale machine?
A: The main products are conveyor belt vulcanizing joint machine, mine explosion-proof conveyor belt vulcanizing machine, conveyor belt repair machine, conveyor belt peeling machine and other corollary equipment.
4. Q: How does your factory do regarding quality control?
A: Quality is priority and we have our own quality control department. We win make a strick inspect in before the machines leave the factory.
5 .Q: Are the technical parameter is fixed?
A: Basically, each model corresponding to the related machine. But we can design different type machine according to the client's requirement.

---
