| MODEL | BX-UP08 | |
| Capacity | 1000VA/600W | |
| INPUT | Voltage | 110V/120 VAC or 220/230/240 VAC |
| Voltage range | 81-145VAC or 145-275VAC | |
| Frequency | 60/50 Hz(Auto sensing) | |
| OUTPUT | Voltage | 110/120 VAC or 220/230/240 VAC |
| Voltage range | ±10% | |
| Frequency range(battery mode) | 60/50±1Hz | |
| Transfer time | 4-6ms | |
| Wave form(battery mode) | Simulated sine wave | |
| BATTERY | Battery model & Quantity | 12V/7AHx2 |
| Charge time | 8 hours recover to 90% capacity | |
| PROTECTION | Full protection | Discharge, Short circuit and overload protection |
| INDICATORS | LCD display | Sounding every 4 seconds |
| ALARM | Low battery | Sounding every second |
| Overload | Sounding every second | |
| Fault | Continuously sounding | |
| INTERFACE | USB/R232 Port (optional) | Support windows XP/Vista, Windows 7/8, Linux, Unix, and MAC |
| Optional SNMP | Power management from SNMP management and web browser | |
| ENVIRONMENT | Humidity | 0-90% RH @ 0-40ºC(Non-condensing) |
| Noise Level | Less than 40dB | |
| Dimension(mm) | 365x140x165 | |
| N.W.(kg) | 10 kg | |
