| US$4,000.00-4,500.00 | 1 Piece (MOQ) |
| Sensor | |
| Receptor Type | a-Si |
| Scintillator | Gos / CsI:TI |
| Active Area | 430 x 430 mm |
| Resolution | 3072 x 3072 |
| Pixel Pitch | 139 μm |
| Power Supply & Battery | |
| Adapter In | AC 100-240V,50-60Hz |
| Adapter Out | DC 24V,2.7A |
| Power Dissipation | <20 W |
| Image Quality | |
| Limiting Resolution | 3.5 LP/mm |
| Energy Range | 40-160 KV |
| Dynamic Range | ≥84 dB |
| Sensitivity | ≥0.54 LSB/nGy |
| Ghos | <1% 1st frame |
| DQE | 42% @(1 LP/mm) 28% @(2 LP/mm) |
| MTF | 68% @(1 LP/mm) 38% @(2 LP/mm) 20% @(3 LP/mm) |
| Electricals and interface | |
| A/D Conversion | 16 bits |
| Data Interface | Gigabit Ethernet |
| Acquire Time | wired: 1s |
| Exposure Control | Software/Sync/AED |
| Mechanical | |
| Dimension | 460 × 460 × 14.8 mm |
| Weight | 3.8kg |
| Material | Aluminum and magnesium alloys |
| Front Panel | Carbon fiber |
| Enviromental | |
| Temperature | 10-35°C (operating);-10~50°C (storage) |
| Humidity | 30-70% RH (non-condensing) |
| Ingress Protection | IP51 |
