Ecoographix Digital Inkjet Printing System Label Smart 108s

Product Description

Product Description Ecoographix Digital inkjet printing system LABEL SMART 108S
Allowing for small-format digital printing and personalized full-color inkjet coding.High cost-effectiveness and reasonable cost of use. Simple and user-friendly printing operation reduces operating costs and brings in higher profits. High-speed, full-color printing, easily transitions in substrate and workflow which allows maximum advantage in digital label printing.
Lable Smart makes single-piece printing possible. An intelligent production system can be set up to realize zero inventory, agile production and point-to-point logistics, and build a new IoT production model. The stable and colorful quality meets the requirements of the digital printing market.
Product Specification

Digital Label Printer Machine
Model	Ecoo Label Modular 108S
Printing Technology	Piezoelectric Inkjet
Print Method	Roll to Roll, One -Side
Color Configuration	Support up to 8 colors
Number Of Channels	8
Maximum Speed	50m/min(CMYK); 25 m/min(CMYK+W)
Resolution	600x600 dpi/600 x1200 dpi
Ink Type	UV Ink
Curing Method	UV LED + Mercury lamp
Media Width	80-330mm
Maximum Print Width	108mm
Media Thickness	50-400um
Media Type	PET, BOPP, PE, BOPA PP, Coated paper, Synthetic paper, Art paper, etc
Maximum Media Roll Diameter	700 mm
Power supply	380V
Power	15 kw
Compressed air	>6.5MPa
Air consumption	>10L/min
Operating environment	Temperature: 20ºC-27ºC, Humidity: 40%-70% relative humidity
Skew Adjustment System	yes
Electrostatic Dust Removal	yes
Water Cooling System	yes
Coating Unit	optional
Digital Varnishing	optional
Cold Foil Stamping	optional
Hot Foil Stamping	optional
Visual inspection	optional

Key benefits
Highly flexible feeding system,suitable for all materials for 80-330mm wide label printing
Imported high-precision industrial print head has higher fire ignition frequency and service life.
The patch tracking electronic eye achieves accurate secondary surprint, comprehensively solves the problem of printing registration.
Broad color gamut UV ink, vivid colors, with the Agfa color management system, can accurately restore the Pantone database colors.
Resolution up to 600 X 1200 dpi
The fully integrated AGFA Apogee prepress workflow system ensures the highest level of reliability.
Automatic winding and unwinding system can effectively prevent the substrate from shifting, ensure the orderliness of the winding and unwinding system and achieve non-stop production for a long time.
Each print head has its own board to control, makes printhead printing more efficiency and easier to maintain.
LED cold light curing unit, energy saving and high efficiency.
Quality Control
Professional control department which is responsible for all the machines.
Full checking list including mechanical and electrical detection on the machine.
Strict standards for registration and over 24 hours of non-stop running on each machine.
Follow the policy of 'One person responsible for one machine',' Claim responsibility if the machine has assembled problem'.
Service
All of our technicians have over 10-20 years experience.
Rich experience in installation, repair, and maintenance overseas.
After-sales staff Whatsapp/Wechat online 24/7.
Guarantee to provide after-sales service for any machine for its whole user life.

---
